12GB RAM (8GB usable) - Overclocking - Page 2

post #11 of 16
Thread Starter
Quote:
Originally Posted by TheReaperWaits;13669600
Are you sure you have home premium?

Home basic has an 8GB limit...

Have you updated to the latest service pack?

Yes, I have Home Premium and Service Pack 1 installed. I also just updated my motherboard to the latest and greatest BIOS (F12).
My System
(13 items)


CPUMotherboardGraphicsRAM
i7-920 GIGABYTE GA-EX58-UD5 X58 HIS Radeon HD4870 CORSAIR XMS3 12GB (6 x 2GB) DDR3 1600
Hard DriveOSMonitorPower
Western Digital Caviar Black WD1002FAEX Windows 7 Home Premium 64-bit ASUS VH226H Black OCZ ModXStream Pro 700W
Case
IN WIN Dragon Rider Black
  hide details
Reply
My System
(13 items)


CPUMotherboardGraphicsRAM
i7-920 GIGABYTE GA-EX58-UD5 X58 HIS Radeon HD4870 CORSAIR XMS3 12GB (6 x 2GB) DDR3 1600
Hard DriveOSMonitorPower
Western Digital Caviar Black WD1002FAEX Windows 7 Home Premium 64-bit ASUS VH226H Black OCZ ModXStream Pro 700W
Case
IN WIN Dragon Rider Black
  hide details
Reply
post #12 of 16
Can I just point out the multi quote button on the bottom right hand corner of every post. wink.gif

Saves you double/triple posting

Fun inside...
(17 items)


CPUGraphicsRAMHard Drive
Athlon 64 3500+ 2.2Ghz 9800GX2 (wet) 1998Mhz Shader 4.5GB mixed WD Caviar black 20GB 'SS'
Optical DriveCoolingOSMonitor
Cheap beige DVD ROM Koolance full copper GX2 block Vista 32bit LG W2486L
PowerCase
Antec EA650 Antec 900
CPUMotherboardGraphicsRAM
I7 920 D0 P6X58D-6 [Full mosfet/Northbridge blocks) GTX480 3x 2GB Dominator 1600Mhz 8-8-8-24
Hard DriveHard DriveHard DriveOptical Drive
M4 64GB WD Green 1.5TB 2x WD CB 640GB Lite-on 22x dual layer, ASUS Blu-ray
CoolingOSMonitorKeyboard
Custom loop Windows 7 64 bit LG W2486L Microsoft (cheapest they had)
PowerCaseMouseMouse Pad
Corsair TX950 Lancool PC-K62 Microsoft X5 Akira theme
Audio
Logitec 5.1
MotherboardRAMHard DriveOptical Drive
EVGA P55 2x 2GB Corsa 2133MHz 250GB DVD-RW
CoolingOSMonitor
Air Vista Business 32bit 17"
  hide details
Reply

Fun inside...
(17 items)


CPUGraphicsRAMHard Drive
Athlon 64 3500+ 2.2Ghz 9800GX2 (wet) 1998Mhz Shader 4.5GB mixed WD Caviar black 20GB 'SS'
Optical DriveCoolingOSMonitor
Cheap beige DVD ROM Koolance full copper GX2 block Vista 32bit LG W2486L
PowerCase
Antec EA650 Antec 900
CPUMotherboardGraphicsRAM
I7 920 D0 P6X58D-6 [Full mosfet/Northbridge blocks) GTX480 3x 2GB Dominator 1600Mhz 8-8-8-24
Hard DriveHard DriveHard DriveOptical Drive
M4 64GB WD Green 1.5TB 2x WD CB 640GB Lite-on 22x dual layer, ASUS Blu-ray
CoolingOSMonitorKeyboard
Custom loop Windows 7 64 bit LG W2486L Microsoft (cheapest they had)
PowerCaseMouseMouse Pad
Corsair TX950 Lancool PC-K62 Microsoft X5 Akira theme
Audio
Logitec 5.1
MotherboardRAMHard DriveOptical Drive
EVGA P55 2x 2GB Corsa 2133MHz 250GB DVD-RW
CoolingOSMonitor
Air Vista Business 32bit 17"
  hide details
Reply
post #13 of 16
I know there is also a memory controle built into the CPU itself... if its currently OC'ed, then you might want to disable the OC and see if all 12 Gigs is detected.

If this isn't the case or the problem then try all of your RAM sticks on another board\PC see if all 12G is detected. If yes, then you know the RAM isn't at fault, and I would suggest you RMA or replace your board.

It nice having spare parts... unfortunatly most people don't have many spare parts to test with.

Good luck!
My AMD/ATI build
(13 items)


CPUMotherboardGraphicsRAM
AMD FX-8350 (4..60Ghz) Gigabyte 990FXA-UD5 XFX R9-290 G.SKILL 8GB DDR3-1600Mhz 7-8-7-24
Hard DriveOSMonitorPower
OCZ Vertex 2 Windows 7 Home 42 Inch Panasonic 1080p Plasma Antec Truepower 750W
  hide details
Reply
My AMD/ATI build
(13 items)


CPUMotherboardGraphicsRAM
AMD FX-8350 (4..60Ghz) Gigabyte 990FXA-UD5 XFX R9-290 G.SKILL 8GB DDR3-1600Mhz 7-8-7-24
Hard DriveOSMonitorPower
OCZ Vertex 2 Windows 7 Home 42 Inch Panasonic 1080p Plasma Antec Truepower 750W
  hide details
Reply
post #14 of 16
I think the two most likely causes are:

1. bad chip on a ram stick.
2. bad dimm slot on motherboard.

Unless it shows the correct amount in bios, this is looking like a hardware issue.

have you tried the other ram slots on the mobo? I recently built a pc using a gigabyte motherboard for a client and one of the ram slots on the motherboard was bad. due to the fact the client just wanted the computer as an internet machine we just used the other ram slots and used the board anyway, because my client did not want to wait for RMA.
Edited by Killam0n - 5/29/11 at 10:15am
Core
(14 items)


CPUMotherboardGraphicsRAM
i7 920 D0 @ 4.0Ghz Asus P6X58D-E Diamond XOC 4870/512 @ 800//4400 Corsair 3x4gb DDR1600
Hard DriveOptical DriveCoolingOS
2x500GB WD RE2 Raid0 Asus Combo, Asus Combo Corsair H80 Windows 7 Ultimate 64bit
MonitorKeyboardPowerCase
HP 2408h Wide Saitek Eclipse II Corsair HX850W Antec 900 Two
MouseMouse Pad
Logitech Mediaplay Cordless Black as in Dark abyss
  hide details
Reply
Core
(14 items)


CPUMotherboardGraphicsRAM
i7 920 D0 @ 4.0Ghz Asus P6X58D-E Diamond XOC 4870/512 @ 800//4400 Corsair 3x4gb DDR1600
Hard DriveOptical DriveCoolingOS
2x500GB WD RE2 Raid0 Asus Combo, Asus Combo Corsair H80 Windows 7 Ultimate 64bit
MonitorKeyboardPowerCase
HP 2408h Wide Saitek Eclipse II Corsair HX850W Antec 900 Two
MouseMouse Pad
Logitech Mediaplay Cordless Black as in Dark abyss
  hide details
Reply
post #15 of 16
Again,its very important that you set the correct qpi voltage for some ram otherwise it will not all be detected correctly.

To have my ram function correctly at its advertised speeds its recommended that the qpi/vtt be run at 1.7volts,if this is not followed then theres no guarantee by the manufacturer that it will run as intended.

Ram comes with XMP- Extreme memory profiles that can be selected in bios,look at my photos to see my ram is set to use 1.7v qpi/vtt to run at 2000Mhz,and 1.6v qpi/vtt to run at 1866Mhz.

As i have previously said i have found that it can actually be run at much lower voltages but still over what Intel reccomend(1.35)and im personally not happy to run over 1.41v for 24/7 under water.

Without the correct qpi/vtt voltage being used(especially with large amounts of ram) it could look as if there is a hadware failure even if theres not.

Can you confirm you have tried to up the qpi/vtt voltage? wth.gif

Le Box of Black
(19 items)


CPUMotherboardGraphicsRAM
i7 930 Gigabyte X58A-UD7 r2.0 GTX 770 16GB Corsair Vengeance in Triple channel mode ;)
Hard DriveHard DriveHard DriveHard Drive
Ocz Vertex 2  Samsung F1  Samsung F3 Samsung F1
Optical DriveOSMonitorKeyboard
Sammie Dvd rw Windows 7 64Bit HZ281HPB 1200p / HP IPS 1080p / Samsung Syncmas... Qpad MK80 (Blue switch), SteelSeries 7G (Cherry...
PowerCaseMouseMouse Pad
HX1000 CM-Stacker 832 Flipped Naos 3200,G5,G400,G400s, G300, Kone+ Razor Destructor and Steelseries Qck
AudioAudioAudio
X-Fi Fatal1ty  ATH-T500 / AH-D510 Samson CO1U PAK Condenser Mic
  hide details
Reply
Le Box of Black
(19 items)


CPUMotherboardGraphicsRAM
i7 930 Gigabyte X58A-UD7 r2.0 GTX 770 16GB Corsair Vengeance in Triple channel mode ;)
Hard DriveHard DriveHard DriveHard Drive
Ocz Vertex 2  Samsung F1  Samsung F3 Samsung F1
Optical DriveOSMonitorKeyboard
Sammie Dvd rw Windows 7 64Bit HZ281HPB 1200p / HP IPS 1080p / Samsung Syncmas... Qpad MK80 (Blue switch), SteelSeries 7G (Cherry...
PowerCaseMouseMouse Pad
HX1000 CM-Stacker 832 Flipped Naos 3200,G5,G400,G400s, G300, Kone+ Razor Destructor and Steelseries Qck
AudioAudioAudio
X-Fi Fatal1ty  ATH-T500 / AH-D510 Samson CO1U PAK Condenser Mic
  hide details
Reply
post #16 of 16
Thread Starter
I cleared CMOS and started from scratch. I was able to get settings that work and lasted an 8 hour stress test from LinX without a problem. I also ran Memtest86 for 5 passes without an error. My temps did reach a high of 77C... then again, my house was 80F. The memory issue is gone (for now). I'm going to post my new settings below and in another forum to see if anyone can see anything that could be tightened up. Maybe a fresh set of eyes can see something I don't to make it a touch better.

Thanks everyone for all the advice.

CPU Clock Ratio [21x]
CPU Frequency: 3.78GHz (180x21)

Advanced CPU Features [Press Enter]:
CPU Clock Ratio [21x]
CPU Frequency: 3.78GHz (180x21)
Intel(R) Turbo Boost Tech [Enabled]
CPU Cores Enabled [All]
CPU Multi-Threading [Enabled]
CPU Enhanced Halt (C1E) [Disabled]
C3/C6/C7 State Support [Enabled
CPU Thermal Monitor [Enabled]
CPU EIST Function [Enabled]
Virtualization Technology [Enabled]
Bi-Directional PROCHOT [Enabled]
Virtualization Technology [Enabled]

QPI Link Ratio [x36]
QPI Link Speed [6.48GHz]

Uncore & QPI Features [Press Enter]:
QPI Clock Ratio [x36]
QPI Link Speed: 6.48GHz
Uncore Clock Ratio [x17]
Uncore Frequency 3060MHz
Isonchronous Frequency [Enabled]

Base Clock (BCLK) Control [Enabled]
BCLK Frequency (MHz) [180]

Advanced Clock Control [Press Enter]:
>>>>> Standard Clock Control
Base Clock (BCLK) Control [Enabled]
BCLK Frequency (MHz) [180]
PCI Express Frequency (MHz) [100]
C.I.A.2 [Disabled]
>>>>> Advanced Clock Control
CPU Clock Drive [ 800mV]
PCI Express Clock Drive [ 900mV]
CPU Clock Skew [ 0ps]
IOH Clock Skew [ 0ps]

Performance Enhance [Standard]
Extreme Memory Profile (X.M.P.) [Disable]
System Memory Multiplier (SPD) [8.0]
Memory Frequency (MHz) 1066 1440
DRAM Timing Selectable (SPD) [Auto]
Profile DDR Voltage 1.5V
Profile QPI Voltage 1.175V

Channel A
CAS Latency Time 8 [Auto]
tRCD 8 [Auto]
tRP 8 [Auto]
tRAS 20 [Auto]
Command Rate (CMD) 2 [Auto]

Channel B
CAS Latency Time 8 [Auto]
tRCD 8 [Auto]
tRP 8 [Auto]
tRAS 20 [Auto]
Command Rate (CMD) 2 [Auto]

Channel C
CAS Latency Time 9 [Auto]
tRCD - [Auto]
tRP - [Auto]
tRAS - [Auto]
Command Rate (CMD) - [Auto]

Advanced DRAM Features [Press Enter]:
Performance Enhance [Standard]
Extreme Memory Profile (X.M.P.) [Disable]
System Memory Multiplier (SPD) [8.0]
Memory Frequency (MHz) 1066 1440
DRAM Timing Selectable (SPD) [Auto]
Profile DDR Voltage 1.5V
Profile QPI Voltage 1.175V
x Channel Interleaving 6 Auto
x Rank Interleaving 4 Auto

>>>>> Channel A
Channel A Timing Settings [Press Enter]:

>>>>> Channel A Standard Timing Control
x CAS Latency Time 8 Auto
tRCD 8 Auto
tRP 8 Auto
tRAS 20 Auto

>>>>> Channel A Advanced Timing Control
x tRC 27 Auto
x tRRD 4 Auto
x tWTR 4 Auto
x tWR 8 Auto
x tWTP 19 Auto
x tWL 7 Auto
x tRFC 60 Auto
x tRTP 4 Auto
x tFAW 20 Auto
x Command Rate (CMD) 2 Auto

>>>>> Channel A Misc Timing Control
x B2B CAS Delay - Auto
x Round Trip Latency 67 Auto

>>>>> Channel A
Channel A Turnaround Settings [Press Enter]:

>>>>> Channel A Writes Followed by Reads
x Different DIMMs 6 Auto
x Different Ranks 6 Auto
x On The Same Rank 6 Auto

>>>>> Channel A Reads Followed by Writes
x Different DIMMs 8 Auto
x Different Ranks 8 Auto
x On The Same Rank 8 Auto

>>>>> Channel A Reads Followed by Reads
x Different DIMMs 6 Auto
x Different Ranks 5 Auto
x On The Same Rank 1 Auto

>>>>> Channel A Writes Followed by Writes
x Different DIMMs 6 Auto
x Different Ranks 6 Auto
x On The Same Rank 1 Auto

>>>>> Channel B
Channel B Timing Settings [Press Enter]:

>>>>> Channel B Standard Timing Control
x CAS Latency Time 8 Auto
tRCD 8 Auto
tRP 8 Auto
tRAS 20 Auto

>>>>> Channel B Advanced Timing Control
x tRC 27 Auto
x tRRD 4 Auto
x tWTR 4 Auto
x tWR 8 Auto
x tWTP 19 Auto
x tWL 7 Auto
x tRFC 60 Auto
x tRTP 4 Auto
x tFAW 20 Auto
x Command Rate (CMD) 2 Auto

>>>>> Channel B Misc Timing Control
x B2B CAS Delay - Auto
x Round Trip Latency 69 Auto

>>>>> Channel B
Channel B Turnaround Settings [Press Enter]:

>>>>> Channel B Writes Followed by Reads
x Different DIMMs 6 Auto
x Different Ranks 6 Auto
x On The Same Rank 6 Auto

>>>>> Channel B Reads Followed by Writes
x Different DIMMs 8 Auto
x Different Ranks 8 Auto
x On The Same Rank 8 Auto

>>>>> Channel B Reads Followed by Reads
x Different DIMMs 6 Auto
x Different Ranks 5 Auto
x On The Same Rank 1 Auto

>>>>> Channel B Writes Followed by Writes
x Different DIMMs 6 Auto
x Different Ranks 6 Auto
x On The Same Rank 1 Auto

>>>>> Channel C
Channel C Timing Settings [Press Enter]:

>>>>> Channel C Standard Timing Control
x CAS Latency Time 8 Auto
tRCD 8 Auto
tRP 8 Auto
tRAS 20 Auto

>>>>> Channel C Advanced Timing Control
x tRC 27 Auto
x tRRD 4 Auto
x tWTR 4 Auto
x tWR 8 Auto
x tWTP 19 Auto
x tWL 7 Auto
x tRFC 60 Auto
x tRTP 4 Auto
x tFAW 20 Auto
x Command Rate (CMD) 2 Auto

>>>>> Channel C Misc Timing Control
x B2B CAS Delay - Auto
x Round Trip Latency 70 Auto

>>>>> Channel C
Channel C Turnaround Settings [Press Enter]:

>>>>> Channel C Writes Followed by Reads
x Different DIMMs 6 Auto
x Different Ranks 6 Auto
x On The Same Rank 6 Auto

>>>>> Channel C Reads Followed by Writes
x Different DIMMs 8 Auto
x Different Ranks 8 Auto
x On The Same Rank 8 Auto

>>>>> Channel C Reads Followed by Reads
x Different DIMMs 6 Auto
x Different Ranks 5 Auto
x On The Same Rank 1 Auto

>>>>> Channel C Writes Followed by Writes
x Different DIMMs 6 Auto
x Different Ranks 6 Auto
x On The Same Rank 1 Auto

Load Line Calibration [Disabled]
CPU Vcore 1.13125v [1.25000v]
QPI/VTT Voltage 1.175v [1.295v]
IOH Core 1.100v [Auto]
DRAM Voltage 1.500v [1.640V]

Advanced Voltage Control [Press Enter]:
Load Line Calibration [Disabled]
CPU Vcore 1.13125v [1.27500v]
x Dynamic Vcore (DVID) +0.00000V Auto
QPI/VTT Voltage 1.175v [1.295v]
CPU PLL 1.800v [1.800V]

>>> MCH/ICH
PCIE 1.500v [Auto]
QPI PLL 1.100v [Auto]
IOH Core 1.100v [Auto]
ICH I/O 1.500v [Auto]
ICH Core 1.100v [Auto]

>>> DRAM
DRAM Voltage 1.500v [1.640V]
DRAM Termination 0.750v [Auto]
Ch-A Data VRef. 0.750v [Auto]
Ch-B Data VRef. 0.750v [Auto]
Ch-C Data VRef. 0.750v [Auto]
Ch-A Address VRef. 0.750v [Auto]
Ch-B Address VRef. 0.750v [Auto]
Ch-C Address VRef. 0.750v [Auto]
My System
(13 items)


CPUMotherboardGraphicsRAM
i7-920 GIGABYTE GA-EX58-UD5 X58 HIS Radeon HD4870 CORSAIR XMS3 12GB (6 x 2GB) DDR3 1600
Hard DriveOSMonitorPower
Western Digital Caviar Black WD1002FAEX Windows 7 Home Premium 64-bit ASUS VH226H Black OCZ ModXStream Pro 700W
Case
IN WIN Dragon Rider Black
  hide details
Reply
My System
(13 items)


CPUMotherboardGraphicsRAM
i7-920 GIGABYTE GA-EX58-UD5 X58 HIS Radeon HD4870 CORSAIR XMS3 12GB (6 x 2GB) DDR3 1600
Hard DriveOSMonitorPower
Western Digital Caviar Black WD1002FAEX Windows 7 Home Premium 64-bit ASUS VH226H Black OCZ ModXStream Pro 700W
Case
IN WIN Dragon Rider Black
  hide details
Reply
New Posts  All Forums:Forum Nav:
  Return Home
  Back to Forum: Intel CPUs
Overclock.net › Forums › Intel › Intel CPUs › 12GB RAM (8GB usable) - Overclocking
