how should i setup my silver arrow and fans?

post #1 of 10
Thread Starter
i'm going to buy the thermalright silver arrow cpu cooler

i was wondering which is the best setup


airflow to the rear exhaust:
fans at 1 & 2
fans at 2 & 3
fans at 1 & 3

OR


airflow to the top exhaust:
