Uneven temps

post #1 of 18
Thread Starter
So I just got my new rig together yesterday and something i've noticed is my core temps are 10 degrees, core 1 being the coldest and core 4 being hotter. Under load and at idle. I'm useing a 2500k with a 212+. I've tried reseating the cooler 4 times, reapplied the TIM useing a rice sized dot in the centre, and tried making a line across the CPU. Still no difference. A friend of mine has a 2500k on a stock cooler and his temps don't variate more than 2-3 degrees. Should I just start RMAing stuff till it goes away or is this normal?
post #2 of 18
Quote:
Originally Posted by bullet_101 View Post
So I just got my new rig together yesterday and something i've noticed is my core temps are 10 degrees, core 1 being the coldest and core 4 being hotter. Under load and at idle. I'm useing a 2500k with a 212+. I've tried reseating the cooler 4 times, reapplied the TIM useing a rice sized dot in the centre, and tried making a line across the CPU. Still no difference. A friend of mine has a 2500k on a stock cooler and his temps don't variate more than 2-3 degrees. Should I just start RMAing stuff till it goes away or is this normal?
I have a similar variation. I've been told that its normal for Intel CPU's to vary like this. I came from AMD cpu that had even temps for all four cores, so I was worried. If you are unhappy with the temps, then you could potentially RMA it, although, if it is working fine, I don't see why you would. Are you planning on overclocking a lot?

Also for a 212+ a rice sized dot of TIM is probably not enough. Most of it probably went into the cracks between the heat sink plate and the heat pipes. You probably want to put a little more than that. The way I did mine was to put thin lines on each of the silver parts between the heat pipes.

What are your temps btw?
post #3 of 18
Thread Starter
25-27 at idle for cores 1 and 2, 33-35 at idle for cores 3 and 4. And yes I'm going to try re applying the TIM again after work, I just saw an example of placing lines of TIM in-between the heat pipes like you said

Yes I do plan on overclocking it to at least 4.5, which I think is pretty close to the limits for this cooler anyways
post #4 of 18
Quote:
Originally Posted by bullet_101 View Post
So I just got my new rig together yesterday and something i've noticed is my core temps are 10 degrees, core 1 being the coldest and core 4 being hotter. Under load and at idle. I'm useing a 2500k with a 212+. I've tried reseating the cooler 4 times, reapplied the TIM useing a rice sized dot in the centre, and tried making a line across the CPU. Still no difference. A friend of mine has a 2500k on a stock cooler and his temps don't variate more than 2-3 degrees. Should I just start RMAing stuff till it goes away or is this normal?
With the Hyper 212, You need MORE that a rice sized bit of Paste. You should apply a good amount to the bottom of the cooler and use something to spread it into the sides of the heat pipes. Get it into those sides good and then use your rice sized bit on the cpu
Red X9
(20 items)


CPUMotherboardGraphicsGraphics
4790K @ 5ghz 1.350v 75c max load temps Asus Maximus VI Formula Evga Gtx Titan X @ 1500mhz / 7800mhz +112mv EK Acetal / Nickel / Nickel back plate
RAMHard DriveHard DriveOptical Drive
Corsair Vengence Pro 32gig 2400mhz c11 red (4x8... 6x 256gig (1.5tb) in Raid 0 , OS / Gaming Drive 2 x Liteon 256gig (512gig) storage drives Asus Dvd-RW
CoolingCoolingCoolingOS
2x 360mm Alphacool XT45 / 1x 480mm Alphacool Mo... EK X-Res 140 D5 vario Pump/Res combo + EK X-top... EK Supreme HF cpu / EK Acetal / Nickel with Nic... Windows 8.1 64bit
MonitorMonitorKeyboardPower
Asus ROG Swift 27" 144hz with G-Sync Samsung 65" 7150  Logitech G510s Corsair AX1200
CaseMouseMouse PadAudio
Thermaltake Core X9 custom painted Red and Black Logitech G602 Wireless Corsair Aluminum Core 2 sided  Bose Companion 5
  hide details
Reply
Red X9
(20 items)


CPUMotherboardGraphicsGraphics
4790K @ 5ghz 1.350v 75c max load temps Asus Maximus VI Formula Evga Gtx Titan X @ 1500mhz / 7800mhz +112mv EK Acetal / Nickel / Nickel back plate
RAMHard DriveHard DriveOptical Drive
Corsair Vengence Pro 32gig 2400mhz c11 red (4x8... 6x 256gig (1.5tb) in Raid 0 , OS / Gaming Drive 2 x Liteon 256gig (512gig) storage drives Asus Dvd-RW
CoolingCoolingCoolingOS
2x 360mm Alphacool XT45 / 1x 480mm Alphacool Mo... EK X-Res 140 D5 vario Pump/Res combo + EK X-top... EK Supreme HF cpu / EK Acetal / Nickel with Nic... Windows 8.1 64bit
MonitorMonitorKeyboardPower
Asus ROG Swift 27" 144hz with G-Sync Samsung 65" 7150  Logitech G510s Corsair AX1200
CaseMouseMouse PadAudio
Thermaltake Core X9 custom painted Red and Black Logitech G602 Wireless Corsair Aluminum Core 2 sided  Bose Companion 5
  hide details
Reply
post #5 of 18
Same story for my processor. My 2nd core always runs 6-10C hotter than the rest of the cores. I've redone the TIM and tried different ways of mounting it.
Parental Advisory
(14 items)


CPUMotherboardGraphicsRAM
i5 2500k: 4.5GHz @ 1.325 Asus Sabertooth P67 EVGA Superclocked 560Ti Corsair XMS3 2x2GB 1600MHz
Hard DriveOptical DriveCoolingOS
WD Caviar Black 500GB x2 in RAID0 Lite-on 24x DVD Burner XSPC RX240 Kit Windows 7 Professional
MonitorKeyboardPowerCase
Acer 21.5" S211HLBD Sidewinder x6 Corsair HX750 HAF 922
MouseMouse Pad
Razer Mamba Cheap-o from Office Depot FTW!
  hide details
Reply
Parental Advisory
(14 items)


CPUMotherboardGraphicsRAM
i5 2500k: 4.5GHz @ 1.325 Asus Sabertooth P67 EVGA Superclocked 560Ti Corsair XMS3 2x2GB 1600MHz
Hard DriveOptical DriveCoolingOS
WD Caviar Black 500GB x2 in RAID0 Lite-on 24x DVD Burner XSPC RX240 Kit Windows 7 Professional
MonitorKeyboardPowerCase
Acer 21.5" S211HLBD Sidewinder x6 Corsair HX750 HAF 922
MouseMouse Pad
Razer Mamba Cheap-o from Office Depot FTW!
  hide details
Reply
post #6 of 18
There is usually a 5 degree difference between my highest and lowest temps when I used the 212+. Ten degrees is a little high, but your temps look fine. What are you temps under load?
Lucy
(15 items)


CPUMotherboardGraphicsRAM
Intel i7 950 3.503Ghz @ 1.04v ASUS Sabertooth X58 EVGA GTX 460 768mb 24.5GB Corsair Dominator
Hard DriveCoolingOSMonitor
Intel 320 Noctua NH D14 Windows 7 Ultimate 64-bit ASUS VW246H
MonitorPowerCaseMouse
ASUS VW246H OCZ ModXStream Pro 700W CoolerMaster HAF X 942 Logitech G9x
  hide details
Reply
Lucy
(15 items)


CPUMotherboardGraphicsRAM
Intel i7 950 3.503Ghz @ 1.04v ASUS Sabertooth X58 EVGA GTX 460 768mb 24.5GB Corsair Dominator
Hard DriveCoolingOSMonitor
Intel 320 Noctua NH D14 Windows 7 Ultimate 64-bit ASUS VW246H
MonitorPowerCaseMouse
ASUS VW246H OCZ ModXStream Pro 700W CoolerMaster HAF X 942 Logitech G9x
  hide details
Reply
post #7 of 18
Thread Starter
Core 1 is 38, Core 2 is 40, Core 3 is 44 and Core 4 is 46 at 100%

I should probably add this is on stock settings, no overclock at all.
post #8 of 18


It's normal. My core 1 sometimes gets 15c over 2-6. Doesn't matter how many times I remount my block.
post #9 of 18
I don't see why you would.
post #10 of 18
Thread Starter
Thanks for all the input. When I'm off work ill try using more paste. If that doesn't work ill just live with it

Sent from my LG-P500 using Tapatalk
