post #6161 of 13812
Quote:
Originally Posted by mandrix View Post

The pump should work in any position as long as it has water coming in from above the pump or enough head pressure to prime it. I've had mine running upside down before with the Bitspower V2 pump top attached.

That's good to know.

Thanks for the help.
No name yet. =(
(15 items)


CPUMotherboardGraphicsRAM
Intel i7 3930k Asus Rampage IV Extreme 2 x EVGA GTX 680 HydroCopper 16GB Corsair Vengeance (4x4)
Hard DriveHard DriveOptical DriveCooling
Primary-Corsair Force Series GT 240GB Storage-WD Caviar Green 1TB LG Blu-Ray Burner Water Cooling
OSMonitorKeyboardPower
Windows 7 Ultimate Samsung S23A950D Corsair Vengeance K90 Corsair AX850
CaseMouseAudio
NZXT Switch 810 (White) Razer Mamba Logitech G930
  hide details
Reply
No name yet. =(
(15 items)


CPUMotherboardGraphicsRAM
Intel i7 3930k Asus Rampage IV Extreme 2 x EVGA GTX 680 HydroCopper 16GB Corsair Vengeance (4x4)
Hard DriveHard DriveOptical DriveCooling
Primary-Corsair Force Series GT 240GB Storage-WD Caviar Green 1TB LG Blu-Ray Burner Water Cooling
OSMonitorKeyboardPower
Windows 7 Ultimate Samsung S23A950D Corsair Vengeance K90 Corsair AX850
CaseMouseAudio
NZXT Switch 810 (White) Razer Mamba Logitech G930
  hide details
Reply
post #6162 of 13812
Thread Starter
Quote:
Originally Posted by willup View Post

Was thinking about getting something like this to clean up my case but I can't figure out how the hell you drain the loop without getting water everywhere

http://www.frozencpu.com/products/13884/ex-res-300/XSPC_Dual_525_Bay_Clear_Reservoir_-_w_D5_Variant_Pump_Installed.html?tl=g30c97s152

I think it would look really good in the 810 switch and paint the faceplate white to match.

What I did is add a on/off valve at the lowest point, and capped it. Then, when I need to drain the loop, I uncap it, attach a piece of tubing to it with a barb and hit the ON position. Then I pull the top LED from my reservoir to create a vacuum and all the water drains. You can see it in this post:

http://www.overclock.net/t/1228934/project-eleven-nzxt-switch-810/10#post_16925175
post #6163 of 13812
Quote:
Originally Posted by protzman View Post

looks like he's using 2m of nzxt white and 2m of red


+REP... Thanks, appreciate it......

"MSI GT70"
(15 items)


CPUGraphicsRAMHard Drive
Intel Core i7 4700MQ NVIDIA Geforce GTX 780M 32GB 1600MHz 128GB SSD Triple Raid
Hard DriveHard DriveHard DriveOptical Drive
128GB SSD 128GB SSD 1TB  Blueray
OSMonitor
Windows 8 Professional  17: 1920x1080
  hide details
Reply

"MSI GT70"
(15 items)


CPUGraphicsRAMHard Drive
Intel Core i7 4700MQ NVIDIA Geforce GTX 780M 32GB 1600MHz 128GB SSD Triple Raid
Hard DriveHard DriveHard DriveOptical Drive
128GB SSD 128GB SSD 1TB  Blueray
OSMonitor
Windows 8 Professional  17: 1920x1080
  hide details
Reply
post #6164 of 13812




Well this would be step one of my full rebuild, a few water cooling goodies and a test bench. Soon to pickup the motherboard and such. Just gotta do it little by little right now tongue.gif
post #6165 of 13812
I was going to switch my case up to a Corsair 800D from my current Corsair C70 but after watching a few video reviews on this case i might be sold on it.

They have a few in white and black in stock at my local Microcenter so i can buy 1 tomorrow if i wish but i have a few observations to make.

This case needs to hold a bunch of water cooling equipment that i ordered as follows -

XSPC EX360 Crossflow Triple 120mm Low Profile Split Fin Radiator-

I am mounting this on the roof of the case but it looks like the top 5.25 tray blocks half the fan. I have a cross flow rad with a port on both ends so how am i going to get tubing back there with out coming in on a crazy angle ?


XSPC EX360 Multiport Triple 120mm Low Profile Split Fin Radiator

I planned on mounting this to the rear of the case and the only way for me to get the tubing in to the case would be through the supplied 4 rubber grommets. I noticed they are slightly offset-ed to the right of the rear exhaust fan mount so hopefully i can angle them and keep a smooth line for the best flow.

Bitspower Water Tank Z-Multi 150 Res -


I need a place to mount this so i would like any ideas from fellow 810 owners where that place could possible be.

As for the pump this is the model i have -


I don't see any solid footing on the bottom of the case to mount this or am i not looking hard enough ?
Edited by nyk20z3 - 7/23/12 at 11:03pm
IN WIN 509 Build
(15 items)


CPUMotherboardGraphicsRAM
Intel 6700k Gigabyte Z170X Ultra Gaming Gigabyte 980 Ti Extreme Gaming G.Skill Ripjaws V DDR4
Hard DriveHard DriveCoolingOS
Intel 750 NVMe Samsung EVO EK 240 Predator Windows 10 64 Bit
MonitorKeyboardPowerCase
Asus ROG Swift Corsair Strafe RGB MX Brown IN WIN Classic 750 IN WIN 805
MouseAudio
Corsair Sabre RGB Corsair SP2500
  hide details
Reply
IN WIN 509 Build
(15 items)


CPUMotherboardGraphicsRAM
Intel 6700k Gigabyte Z170X Ultra Gaming Gigabyte 980 Ti Extreme Gaming G.Skill Ripjaws V DDR4
Hard DriveHard DriveCoolingOS
Intel 750 NVMe Samsung EVO EK 240 Predator Windows 10 64 Bit
MonitorKeyboardPowerCase
Asus ROG Swift Corsair Strafe RGB MX Brown IN WIN Classic 750 IN WIN 805
MouseAudio
Corsair Sabre RGB Corsair SP2500
  hide details
Reply
post #6166 of 13812
Did you get a 240 or 320? The pic doesn't match the description lol. I'm guessing 320 since you are asking about the 5.25in bays.

As for the res, most of us mount it between the 5.25 bays and the motherboard. using either the existing grommets or drilling small holes for the supports.
post #6167 of 13812
Quote:
Originally Posted by sticks435 View Post

Did you get a 240 or 320? The pic doesn't match the description lol. I'm guessing 320 since you are asking about the 5.25in bays.
As for the res, most of us mount it between the 5.25 bays and the motherboard. using either the existing grommets or drilling small holes for the supports.

Its a 360 lol sry i put 240 by accident.

I may have to return the crossflow for another multiport so i don't have to run tubing that close to the 5.25 bay.

I have checked through almost every page and have not seen any run a rad on the rear of the case so if i do go with this case at least i can provide some more insight on that.

I still have a feeling like i would have more room to work with if i go with a 800D so with that said they are both in stock at Micocenter so i will make my choice tomorrow.

The switch has nice and up to date features but its obvious i need a lot of room to mount everything in a efficient manner. The switch might not be able to provide that esp with no solid footing on the bottom for a res which is where i would like to mount it.

For example -

If you look here i can mount the pump in the psu heat zone or on the tray above it with double sided Velcro oppose to the Switch where i have no where to bolt or stick it 2.


$$ is not an issue so if i really need to go with the 800D i will but i am very impressed with the Switch so far but it might just come up a little short for me.

I will update tomorrow..
IN WIN 509 Build
(15 items)


CPUMotherboardGraphicsRAM
Intel 6700k Gigabyte Z170X Ultra Gaming Gigabyte 980 Ti Extreme Gaming G.Skill Ripjaws V DDR4
Hard DriveHard DriveCoolingOS
Intel 750 NVMe Samsung EVO EK 240 Predator Windows 10 64 Bit
MonitorKeyboardPowerCase
Asus ROG Swift Corsair Strafe RGB MX Brown IN WIN Classic 750 IN WIN 805
MouseAudio
Corsair Sabre RGB Corsair SP2500
  hide details
Reply
IN WIN 509 Build
(15 items)


CPUMotherboardGraphicsRAM
Intel 6700k Gigabyte Z170X Ultra Gaming Gigabyte 980 Ti Extreme Gaming G.Skill Ripjaws V DDR4
Hard DriveHard DriveCoolingOS
Intel 750 NVMe Samsung EVO EK 240 Predator Windows 10 64 Bit
MonitorKeyboardPowerCase
Asus ROG Swift Corsair Strafe RGB MX Brown IN WIN Classic 750 IN WIN 805
MouseAudio
Corsair Sabre RGB Corsair SP2500
  hide details
Reply
post #6168 of 13812
Its possible i can go with a bay res and put some form of gel padding on the floor and mount the pump on that because i will be honest guys i am loving this case in white.


And then mount the pump as follows -

On this


Or


Or return my pump and res and a do a res/pump combo because that's the only solution i can see to really clean things up here.

http://www.frozencpu.com/products/13884/ex-res-300/XSPC_Dual_525_Bay_Clear_Reservoir_-_w_D5_Variant_Pump_Installed.html?tl=g30c97s152&id=yKQZcLjC&mv_pc=2691#blank

Should i stick with the included Alphacool pump or upgrade 2 a MCP655 ?
Edited by nyk20z3 - 7/24/12 at 12:52am
IN WIN 509 Build
(15 items)


CPUMotherboardGraphicsRAM
Intel 6700k Gigabyte Z170X Ultra Gaming Gigabyte 980 Ti Extreme Gaming G.Skill Ripjaws V DDR4
Hard DriveHard DriveCoolingOS
Intel 750 NVMe Samsung EVO EK 240 Predator Windows 10 64 Bit
MonitorKeyboardPowerCase
Asus ROG Swift Corsair Strafe RGB MX Brown IN WIN Classic 750 IN WIN 805
MouseAudio
Corsair Sabre RGB Corsair SP2500
  hide details
Reply
IN WIN 509 Build
(15 items)


CPUMotherboardGraphicsRAM
Intel 6700k Gigabyte Z170X Ultra Gaming Gigabyte 980 Ti Extreme Gaming G.Skill Ripjaws V DDR4
Hard DriveHard DriveCoolingOS
Intel 750 NVMe Samsung EVO EK 240 Predator Windows 10 64 Bit
MonitorKeyboardPowerCase
Asus ROG Swift Corsair Strafe RGB MX Brown IN WIN Classic 750 IN WIN 805
MouseAudio
Corsair Sabre RGB Corsair SP2500
  hide details
Reply
post #6169 of 13812
There are several locations to stick a res or pump in an 810 if you get creative. A lot of folks also like the bay reservoirs. It all depends on how comfortable you are doing simple mods.
As far as a 360 rad being partially blocked up top, there is an easy solution for that if you don't mind cutting that tray up top. I cut half of mine, leaving a good place for a fan controller with no or very minimal interference to air flow.
Check my build log for some ideas.

EDIT: I have my D5 mounted on one of those double sticky foam pads that came with the pump.
post #6170 of 13812
UPGRATE









Tha G1-Killer RIG
(11 photos)

Reply
Tha G1-Killer RIG
(11 photos)
