I did some updates to the build.

The specs for this build are as follows:
Case- In Win Dragon Slayer mATX case
CPU-i5-3570K
Motherboard- Asus Maximus IV GENE Z/GEN 3
GPU- EVGA GTX 460
Memory- Mushkin 8GB (2x4GB DDR3 PC3-16000 9-11-9-27 Ridgeback
PSU- Corsair AX-650
SSD-Corsair Force 3 90 GB
HDD- Seagate Barracuda 360 GB 7200rpm
Cooling- XSPC RayStorm, XSPC EX240 radiator, Bitspower Water Tank Z -Multi Option 150 Reservoir, Swiftech MCP35B Pump.
Fans- 2 Scythe Slipstream Slim fans & 2 Enermax T.B. Silence

Future plans include adding another 240 radiator, adding a EVGA GTX 670 SC with a RayStorm 670 water block, Bitfenix Alchemy White LED, Mayhems Pastel Grape Red coolant and PrimoFlex Pro LRT Black Tubing -3/8in. ID X 1/2in. OD.
