[Build Log] mATX 'The Green Rose' - Page 3

post #21 of 41
Thread Starter
One other thing... I think I need to change the name of this project to the 'Green Rose'.thumb.gif

EDIT: Name officially changed to the Green Rose thumb.gif


and SLEEVING SUCKS. :-(
Edited by 350 Malibu - 10/14/12 at 8:18am
post #22 of 41
Yep hahaha sleeving is the only thing holding me back from my new computer. Started yesterday and wanna kill myself biggrin.gif
post #23 of 41
Thread Starter
Out with the old, and in with the new. Completed the 24/8 pin MB cables. What a pain in the arse. redface.gif

Out with the old

In with the new

Not perfect, but I can live with it for now... I wish the cables were a bit more organized and cleaner at the 24 pin plug. I made all the wires one length, but since the plugs at the PSU are at different heights, the wires look separated and funky at the MB. The 10 pin connecter wires are stretched a bit farther then the 18 pin plug.

Dig the cheap Neon Green cable ties I picked up at Fry's, lol. biggrin.gif

View from top of case


Still waiting for my last order from performance pc's to finish the case. mad.gif
Edited by 350 Malibu - 10/14/12 at 8:12am
post #24 of 41
love the acrylic. Where did you get it and how much did it cost?

+subbed
post #25 of 41
Thread Starter
Quote:
Originally Posted by droses1 View Post

love the acrylic. Where did you get it and how much did it cost?
+subbed


Thanks for the sub, the acrylic sheet is from performance pc's, $20 for a 19"x19" sheet. Not cheap, but is good stuff, 5mm thick.
post #26 of 41
Thread Starter
Well today I got the ram correctly colored, and a few minor things done, which is about all I can do until the rest of the stuff is delivered.

Started with the boring ram...

stripped it down

Properly finished, the way GSkill should have done it! Even saved the spec sticker. tongue.gif

Installed - I'm considering buying 2 more sticks of the ram just to fill up the open slots. It's cheap stuff. thumb.gif

Tested and started to sleeve up the LED wires, had everything working until I sleeved the wires and the resistors fell apart. Pulled the heat shrink off the resistors and the leads were rusted completely gone. mad.gif That's the last time I buy the pre-wired LED's, I'll stick with wiring up my own from now on. Green LEDs look blue in the picture, but are quite green, I just have a crappy iPhone for pictures.

What else can I show tonight........ Oh the Samsung 830 512GB found it's final resting spot.


Here was my inspiration for the name change to the Green Rose (wife likes roses and green stuff, so what the hell).

Then I got a little crazy with it and free handed a rose onto the back side acrylic with 1/4" pin-striping tape. Looking at it now, it looks more like a tulip. weirdsmiley.gif I threw it in the blast cabinet, and etched the inside of the acrylic on the back side and the inside top. It is transparent enough to see through, and you can see the rose in the etch on the side of the case. Wife liked it, so all good. The other side will stay clear so the goodies can be easily seen.

That is it for it today. Hope to get more done tomorrow.
post #27 of 41
Thread Starter
Finally got the last of the parts in yesterday, so mass assembly started shortly afterward.

Cable management the best way I know with nowhere to hide the cables.

Cooling loop in, starting to fill her up with some green fluid.


The rest shall speak for themselves:







Finished installing OS last night and moving the wife's profile data onto it. She has never used more than 35-40GB of disk space, so I think I might be replacing the 512GB SSD with a 128GB and reusing the 512GB in my next build. Seems like such a waste in this machine that will barely be used.

I am still waiting for some replacement LED's. I bought 2 more sticks of RAM and need to fix a couple minor issues, but I would call this build 99.9% complete. I will try and get better pictures up once I get a hold of my daughters camera.

Thanks for looking...thumb.gif
Edited by 350 Malibu - 10/17/12 at 8:38am
post #28 of 41
WOW, great work on the cables and painting the ram sinks, very clean build! thumb.gif
POLARIS
(14 items)

Red Alert SR-1
(14 items)


CPUMotherboardGraphicsRAM
Intel 3570k 4.5Ghz 1.25v AsRock z77E-ITX XFX Reference 2GB 6950 1015/1500 1.255v 8gb Gskill Trident X 2400 C10
Hard DriveCoolingOSMonitor
Samsung 830 128GB Ek Supreme HF White Acetal/EK FC 6970 Windows 7 Dell U2913WM 2560x1080
PowerCaseMouseAudio
Cooler Master Silent Pro Hybrid 1050w Caselabs Mercury S3 Logitech G500 Fiio E10k USB DAC
Audio
Creative Aurvana Live!
CPUMotherboardGraphicsRAM
Phenom II 955 BE (4.4Ghz @1.52v) NB @ 2870 Gigabyte 990FXA-UD3 Rev. 1.1 [F4] Dual Reference XFX 2GB 6950s (950/1437) 1.25v 8GB Gskill DDR3 1333 CL7 @1412
Hard DriveCoolingOSMonitor
Vertex II 60GB, 2x Caviar Black EK Supreme HF, EK FC 6970 Windows 7 Ultimate Alienware AW2210 1080p
KeyboardPowerCaseMouse
Logitech Illuminated Corsair 650TX Cooler Master Storm Scout Logitech G9
  hide details
Reply
POLARIS
(14 items)

Red Alert SR-1
(14 items)


CPUMotherboardGraphicsRAM
Intel 3570k 4.5Ghz 1.25v AsRock z77E-ITX XFX Reference 2GB 6950 1015/1500 1.255v 8gb Gskill Trident X 2400 C10
Hard DriveCoolingOSMonitor
Samsung 830 128GB Ek Supreme HF White Acetal/EK FC 6970 Windows 7 Dell U2913WM 2560x1080
PowerCaseMouseAudio
Cooler Master Silent Pro Hybrid 1050w Caselabs Mercury S3 Logitech G500 Fiio E10k USB DAC
Audio
Creative Aurvana Live!
CPUMotherboardGraphicsRAM
Phenom II 955 BE (4.4Ghz @1.52v) NB @ 2870 Gigabyte 990FXA-UD3 Rev. 1.1 [F4] Dual Reference XFX 2GB 6950s (950/1437) 1.25v 8GB Gskill DDR3 1333 CL7 @1412
Hard DriveCoolingOSMonitor
Vertex II 60GB, 2x Caviar Black EK Supreme HF, EK FC 6970 Windows 7 Ultimate Alienware AW2210 1080p
KeyboardPowerCaseMouse
Logitech Illuminated Corsair 650TX Cooler Master Storm Scout Logitech G9
  hide details
Reply
post #29 of 41
Thread Starter
Quote:
Originally Posted by Shadow_Foxx View Post

WOW, great work on the cables and painting the ram sinks, very clean build! thumb.gif

Thanks.

I have one PCIe Cable almost finished as well to match the white cables @ the PSU, but not sure I need it yet. I may or may not get a GPU for this. My wife does not game, so if I get a GPU for it, it would only be for my son to play on with his games. A smallish GTX 550 or 560 ti should be more than enough I think.

I had 2 more sticks of ram delivered in the mail today, so I will get those painted up tomorrow or this weekend and installed. Still waiting on new LED's/resistors to get the lighting finished. Also came across some really neat coolant I am thinking of getting, the Mayhem Aurora Green. It would make the cooling loop look a lot better I think behind this green acrylic you could actually see it moving. I can't even tell it has liquid in it as it sits! rolleyes.gif

Anyone have experience with Mayhem Aurora cooling fluid?? Currently running EK UV green.
post #30 of 41
The Aurora fluids will clog up your loop.
