[Build Log] --- The Liquidator -- 99% COMPLETED. - Page 5

post #41 of 523
Thread Starter
Okay, here's some updates. I finally got the components I ordered last week. I still need to get a few things, like some 90 degree angles, and some extensions - maybe even some extra tubing in case of a mistake, but overall I have the majority of parts I need. I did a test of where I plan on putting the two D5's, and so far I'm happy with the results. The place that I put them will be totally undetectable to the naked eye. I've also decided to go with a backup reservoir, in case those flow indicators don't house enough liquid.

As for getting started on deconstructing my old rig to transfer my hardware over to this one, I'll have to get some of the logistics on this rig finished first, such as installing the LED lighting strips, grinding a little more material off the horizontal midplate along the motherboard tray so that it levels off when facing the front of the case, and figuring out how I want to plumb the flow indicators. Somewhere on the vertical midplate I'll also need to bore a couple of holes for the Motherboard in order to reach the plumbing in the front of the case. If I have some time this weekend, I'll probably install the lighting and do some fabricating to get some things to fit correctly. Whatever I get done, I'll have an update by or before next weekend.

Okay, here's what I've received so far:


Edited by ProfeZZor X - 1/3/14 at 1:08pm
