HDD Cage:

Surfing OCN while working is a nice balance of activities.




To work!

To mount the rails for HDD’s and allow for recessed mounting hardware, a counter-sink was used to open up the outside hole that was drilled for the mounting hardware:







Holes drilled, cleaned up and ready for a test-mount.













The inner edges of the HDD cage counterparts the HDD rails needed some padding to prevent excessive scratching. Additionally this self-adhesive (dense) felt doubles as the friction-lock and anti-vibration measure.







The side panels for the HDD and the ½†strain reliefs (used for power cords at the point that it leaves the body of the object) that work well as plugs.








Test fit of a single HDD.





Completed HDD cage (more clean-up of the profiles needs to be done):










Checking fitment in the lower chamber:














Next step is to do some finish-work and attention to detail, then mount the cage permanently in the lower chamber followed by the fabrication of the upper chamber components and panels.


Thank you for taking a gander.
