Official EVGA X58 SLI/LE/Micro MB Owners Club - Page 26

post #251 of 2630
Quote:
Originally Posted by Elementality View Post
My Settings:

Frequency Control
CPU Clock Ratio ( 20x )
CPU Host Frequency (Mhz) ( 191 )
MCH Strap ( Auto )
CPU Uncore Frequency (Mhz) ( Auto )
CPU Clock Skew ( 0 ps )
Spread Spectrum ( Disabled )
PCIE Frequency (Mhz) ( 100 )
OC Recorvery ( Enabled )
Turbo Performance (Enabled)

Voltage Control
EVGA VDroop Control ( Without VDroop )
CPU VCore ( 1.275 )
CPU VTT Voltage ( +100 )
CPU PLL VCore ( Auto )
DIMM Voltage ( 1.65 )
DIMM DQ Vref ( +0mV )
QPI PLL VCore ( 1.35 )
IOH VCore ( 1.2 )
IOH/ICH I/O Voltage ( Auto )
ICH VCore ( 1.2 )

CPU Feature
Intel SpeedStep ( Disabled )
Turbo Mode Function ( Enabled )
CxE Function ( Disabled )
Execute Disable Bit ( Disabled )
Virtualization Technology ( Disabled )
Intel HT Technology ( Enabled )
Active Processor Cores ( All )
QPI Control Settings ( Enabled )
QPI Link Fast Mode ( Enabled )
QPI Frequency Selection ( 4.800 GT/s )
So I used this as a guide to try and get up to 4 ghz and well it wasnt stable so I had to up the voltage to 1.35 and I still couldn't run the bclk at 191 so I set it to 184.



I am new at this overclocking so I dont really know what settings to tinker with to get the best effiency.

Edited by Hemby37 - 3/4/10 at 6:50am
Ex
(13 items)


CPUMotherboardGraphicsRAM
Intel i7 920 4.0ghz eVGA x58 SLI LE eVGA GTX 275 896 mb Corsair XMS3 6GB DDR3, 1600MHz
Hard DriveOSMonitorPower
1tb Seagate 7200rpm Windows 7 Ultimate x64 Samsung 2343BWX Corsair TX 750watt psu
Case
Antec Nine Hundred
  hide details
Reply
Ex
(13 items)


CPUMotherboardGraphicsRAM
Intel i7 920 4.0ghz eVGA x58 SLI LE eVGA GTX 275 896 mb Corsair XMS3 6GB DDR3, 1600MHz
Hard DriveOSMonitorPower
1tb Seagate 7200rpm Windows 7 Ultimate x64 Samsung 2343BWX Corsair TX 750watt psu
Case
Antec Nine Hundred
  hide details
Reply

Gear mentioned in this thread:

post #252 of 2630
Quote:
Originally Posted by Hemby37 View Post
So I used this as a guide to try and get up to 4 ghz and well it wasnt stable so I had to up the voltage to 1.35 and I still couldn't run the bclk at 191 so I set it to 184.

I am new at this overclocking so I dont really know what settings to tinker with to get the best effiency.
Did you copy my memory settings as well because I see you have different memory from me. Also every chip is different meaning some can hold a stable 1.25v VCore for 4GHz and some need up to 1.275v Its all up to the chip and what it likes, think of a teenage girl and clothes......VERY picky lol.
Blue
(13 items)


CPUMotherboardGraphicsRAM
i7 920 @ 4GHz EVGA X58 LE EVGA GTX285 2GB 12GB OCZ Platinum 1600MHz (7-7-7-24)
Hard DriveOptical DriveOSKeyboard
1x OCZ 60GB Vertex 1x Seagate 320GB Barracuda Sony OEM Lightscribe Win 7 Professional 64-bit Razer Lycosa
PowerCaseMouse
Antec 850 Semi-Modular CPX Antec 1200 Razer Naga
  hide details
Reply
Blue
(13 items)


CPUMotherboardGraphicsRAM
i7 920 @ 4GHz EVGA X58 LE EVGA GTX285 2GB 12GB OCZ Platinum 1600MHz (7-7-7-24)
Hard DriveOptical DriveOSKeyboard
1x OCZ 60GB Vertex 1x Seagate 320GB Barracuda Sony OEM Lightscribe Win 7 Professional 64-bit Razer Lycosa
PowerCaseMouse
Antec 850 Semi-Modular CPX Antec 1200 Razer Naga
  hide details
Reply
post #253 of 2630
Quote:
Originally Posted by Elementality View Post
Did you copy my memory settings as well because I see you have different memory from me. Also every chip is different meaning some can hold a stable 1.25v VCore for 4GHz and some need up to 1.275v Its all up to the chip and what it likes, think of a teenage girl and clothes......VERY picky lol.

i left the ram alone. i am scared to change that. that brings up another point. I know I have ddr3 1600 ram but when I boot up it shows at 1066mhz. Any ideas why?

I have been gettin different advice, like going to 20x instead of 21x and lower the vcore and then go from there. Any tips would be great since I seem to suck at this lol
Ex
(13 items)


CPUMotherboardGraphicsRAM
Intel i7 920 4.0ghz eVGA x58 SLI LE eVGA GTX 275 896 mb Corsair XMS3 6GB DDR3, 1600MHz
Hard DriveOSMonitorPower
1tb Seagate 7200rpm Windows 7 Ultimate x64 Samsung 2343BWX Corsair TX 750watt psu
Case
Antec Nine Hundred
  hide details
Reply
Ex
(13 items)


CPUMotherboardGraphicsRAM
Intel i7 920 4.0ghz eVGA x58 SLI LE eVGA GTX 275 896 mb Corsair XMS3 6GB DDR3, 1600MHz
Hard DriveOSMonitorPower
1tb Seagate 7200rpm Windows 7 Ultimate x64 Samsung 2343BWX Corsair TX 750watt psu
Case
Antec Nine Hundred
  hide details
Reply
post #254 of 2630
Quote:
Originally Posted by Hemby37 View Post
i left the ram alone. i am scared to change that. that brings up another point. I know I have ddr3 1600 ram but when I boot up it shows at 1066mhz. Any ideas why?

I have been gettin different advice, like going to 20x instead of 21x and lower the vcore and then go from there. Any tips would be great since I seem to suck at this lol
you have the multi set up to go to 1066, check in the memory settings to bump up the ratio.

Also memory multi has to be half of the QPI multi i believe or it really helps with stability, I Usually use 16x (QPI) and 8x (Memory)

CPUMotherboardGraphicsRAM
Intel Core i7 930 [4.33 Ghz] EVGA X58 SLI LE EVGA GTS 450 [SLI] 6 GB DDR 3 OCZ 1600 [1T-7-8-7-18 @ 1474]
Hard DriveOptical DriveOSMonitor
Vertex 2 [120 GB] + 4x WD Green 2 TB [Raid1] Samsung BD-R [12x] Microsoft Windows 7 Pro [x64] [3] Samsung SyncMaster 2233sw
KeyboardPowerCaseMouse
I-rocks Corsair HX650 [650W] Lian Li PC K62 Logi
Mouse Pad
Metallica
  hide details
Reply

CPUMotherboardGraphicsRAM
Intel Core i7 930 [4.33 Ghz] EVGA X58 SLI LE EVGA GTS 450 [SLI] 6 GB DDR 3 OCZ 1600 [1T-7-8-7-18 @ 1474]
Hard DriveOptical DriveOSMonitor
Vertex 2 [120 GB] + 4x WD Green 2 TB [Raid1] Samsung BD-R [12x] Microsoft Windows 7 Pro [x64] [3] Samsung SyncMaster 2233sw
KeyboardPowerCaseMouse
I-rocks Corsair HX650 [650W] Lian Li PC K62 Logi
Mouse Pad
Metallica
  hide details
Reply
post #255 of 2630
Quote:
Originally Posted by sdla4ever View Post
you have the multi set up to go to 1066, check in the memory settings to bump up the ratio.

Also memory multi has to be half of the QPI multi i believe or it really helps with stability, I Usually use 16x (QPI) and 8x (Memory)

Well it wasnt me who set it up like that. Thats how the defaults were because i havent messed with any ram timings or anything.

Is 16x (QPI) and 8x (memory) what I should use? I dont know much about Overclocking and for sure dont know much about what to set my ram timing at lol!
Ex
(13 items)


CPUMotherboardGraphicsRAM
Intel i7 920 4.0ghz eVGA x58 SLI LE eVGA GTX 275 896 mb Corsair XMS3 6GB DDR3, 1600MHz
Hard DriveOSMonitorPower
1tb Seagate 7200rpm Windows 7 Ultimate x64 Samsung 2343BWX Corsair TX 750watt psu
Case
Antec Nine Hundred
  hide details
Reply
Ex
(13 items)


CPUMotherboardGraphicsRAM
Intel i7 920 4.0ghz eVGA x58 SLI LE eVGA GTX 275 896 mb Corsair XMS3 6GB DDR3, 1600MHz
Hard DriveOSMonitorPower
1tb Seagate 7200rpm Windows 7 Ultimate x64 Samsung 2343BWX Corsair TX 750watt psu
Case
Antec Nine Hundred
  hide details
Reply
post #256 of 2630
Quote:
Originally Posted by Hemby37 View Post
Well it wasnt me who set it up like that. Thats how the defaults were because i havent messed with any ram timings or anything.

Is 16x (QPI) and 8x (memory) what I should use? I dont know much about Overclocking and for sure dont know much about what to set my ram timing at lol!
Change the RAM timings to 8-8-8-24-88-1T. i think you have the same kit as me?
post #257 of 2630
Quote:
Originally Posted by Hemby37 View Post
Well it wasnt me who set it up like that. Thats how the defaults were because i havent messed with any ram timings or anything.

Is 16x (QPI) and 8x (memory) what I should use? I dont know much about Overclocking and for sure dont know much about what to set my ram timing at lol!
Ya set it to those and set the timings to 8-8-8-24-1T you can try 1T but 2T will have a better chance of being stable and if you arent gonna bench heavily the difference is not noticeable.

CPUMotherboardGraphicsRAM
Intel Core i7 930 [4.33 Ghz] EVGA X58 SLI LE EVGA GTS 450 [SLI] 6 GB DDR 3 OCZ 1600 [1T-7-8-7-18 @ 1474]
Hard DriveOptical DriveOSMonitor
Vertex 2 [120 GB] + 4x WD Green 2 TB [Raid1] Samsung BD-R [12x] Microsoft Windows 7 Pro [x64] [3] Samsung SyncMaster 2233sw
KeyboardPowerCaseMouse
I-rocks Corsair HX650 [650W] Lian Li PC K62 Logi
Mouse Pad
Metallica
  hide details
Reply

CPUMotherboardGraphicsRAM
Intel Core i7 930 [4.33 Ghz] EVGA X58 SLI LE EVGA GTS 450 [SLI] 6 GB DDR 3 OCZ 1600 [1T-7-8-7-18 @ 1474]
Hard DriveOptical DriveOSMonitor
Vertex 2 [120 GB] + 4x WD Green 2 TB [Raid1] Samsung BD-R [12x] Microsoft Windows 7 Pro [x64] [3] Samsung SyncMaster 2233sw
KeyboardPowerCaseMouse
I-rocks Corsair HX650 [650W] Lian Li PC K62 Logi
Mouse Pad
Metallica
  hide details
Reply
post #258 of 2630
Quote:
Originally Posted by McLaren_F1 View Post
Change the RAM timings to 8-8-8-24-88-1T. i think you have the same kit as me?
I dont have the DOMINATOR version. I have the other 6gb kit.
Ex
(13 items)


CPUMotherboardGraphicsRAM
Intel i7 920 4.0ghz eVGA x58 SLI LE eVGA GTX 275 896 mb Corsair XMS3 6GB DDR3, 1600MHz
Hard DriveOSMonitorPower
1tb Seagate 7200rpm Windows 7 Ultimate x64 Samsung 2343BWX Corsair TX 750watt psu
Case
Antec Nine Hundred
  hide details
Reply
Ex
(13 items)


CPUMotherboardGraphicsRAM
Intel i7 920 4.0ghz eVGA x58 SLI LE eVGA GTX 275 896 mb Corsair XMS3 6GB DDR3, 1600MHz
Hard DriveOSMonitorPower
1tb Seagate 7200rpm Windows 7 Ultimate x64 Samsung 2343BWX Corsair TX 750watt psu
Case
Antec Nine Hundred
  hide details
Reply
post #259 of 2630
Quote:
Originally Posted by Hemby37 View Post
I dont have the DOMINATOR version. I have the other 6gb kit.
theres a few other 6gb kits. Which one?

http://www.corsair.com/products/xms3/default.aspx
post #260 of 2630
Quote:
Originally Posted by Hemby37 View Post
So I used this as a guide to try and get up to 4 ghz and well it wasnt stable so I had to up the voltage to 1.35 and I still couldn't run the bclk at 191 so I set it to 184.



I am new at this overclocking so I dont really know what settings to tinker with to get the best effiency.
Try setting the IOH manually. For around 4GHz I need 1.1v, but I personally think I have a very good CPU. You can try up to 1.25-1.3v.

Quote:
Originally Posted by sdla4ever View Post
you have the multi set up to go to 1066, check in the memory settings to bump up the ratio.

Also memory multi has to be half of the QPI multi i believe or it really helps with stability, I Usually use 16x (QPI) and 8x (Memory)
Yup, 16x QPI and 8X RAM divider works best for me.
B&W
(13 items)


CPUMotherboardGraphicsRAM
AMD Ryzen 7 1700 ASUS ROG CROSSHAIR VI HERO (WI-FI AC) Nvidia GeForce GTX 1080 G.SKILL TridentZ RGB Series 16GB (2 x 8GB) 288-...
Hard DriveCoolingOSMonitor
Samsung 850 EVO 500GB SSD (OS)// OCZ Vertex 4 1... EK Water blocks P280 Water Cooling Kit Windows 10 64 Bit Home Edition Samsung 40" LED 4K TV
PowerCase
EVGA SuperNOVA 1000 G2 120-G2 Corsair Obsidian 900D
  hide details
Reply
B&W
(13 items)


CPUMotherboardGraphicsRAM
AMD Ryzen 7 1700 ASUS ROG CROSSHAIR VI HERO (WI-FI AC) Nvidia GeForce GTX 1080 G.SKILL TridentZ RGB Series 16GB (2 x 8GB) 288-...
Hard DriveCoolingOSMonitor
Samsung 850 EVO 500GB SSD (OS)// OCZ Vertex 4 1... EK Water blocks P280 Water Cooling Kit Windows 10 64 Bit Home Edition Samsung 40" LED 4K TV
PowerCase
EVGA SuperNOVA 1000 G2 120-G2 Corsair Obsidian 900D
  hide details
Reply
