AMD Athalon II X4 640 @ 3.4 As good as it gets? - Page 4

post #31 of 85
Thread Starter
Go for it Rookie1337, threadjacker:) Looks like we are in a race here as it is. Here are my settings line for line from the Bios in its Term, help me translate the voltage settings as it looks like there are duplicates.

Currently Stable(will test through the night):
CPU FSB 240
CPU Mult: 15x
CPU Freq: 3600
CPU_NB Mult:8x
CPU_NB Freq: 1920
FSB:RAM Ratio: 1:3.33
RAM Freq: 1600
HT Mult: 8x
HT Freq: 1920
Voltages
CPU VDD: Auto (1.25)
CPU_NB VDD: Auto(1.25)
CPU Voltage: 1.53
CPU NB Voltage: Auto(1.2)
Dram Voltage: 1.65
NB Voltage: Auto (1.08)
HT Link: Auto (1.20)

Everyone says raise your nb voltage, I head palm because I have 3 of them. I will try to get 3.75 Stable tomorrow if 3.6 is good to go. {Hopefully} bigger pics as requested.
WhereIam-1.jpg?t=1293601215
Large-1.jpg?t=1293601250
AndNow-1.jpg?t=1293601275
They are on the bucket and might get bandwidth limited after a while.
BullDriver
(13 items)


CPUMotherboardGraphicsRAM
FX-8350 Vishera 4.0GHz Asus 990FX Sabertooth MSI N465GTX 8gb Gskill Sniper 1600/9.9.9.25
Hard DriveOptical DriveOSMonitor
64Gb Crucial SSD(os) +1tb Baracuda SataIII Asus OEM SATA DVD RW x64 Windows 7 Home Premium 25" Hanns G
KeyboardPowerCaseMouse
Microsoft Flatty Tethered RocketFish 550w Modular Corsair 600t Logitech MX Revolution
  hide details
Reply
BullDriver
(13 items)


CPUMotherboardGraphicsRAM
FX-8350 Vishera 4.0GHz Asus 990FX Sabertooth MSI N465GTX 8gb Gskill Sniper 1600/9.9.9.25
Hard DriveOptical DriveOSMonitor
64Gb Crucial SSD(os) +1tb Baracuda SataIII Asus OEM SATA DVD RW x64 Windows 7 Home Premium 25" Hanns G
KeyboardPowerCaseMouse
Microsoft Flatty Tethered RocketFish 550w Modular Corsair 600t Logitech MX Revolution
  hide details
Reply
post #32 of 85
I think I'm screwed. I'm going to drop back down to 3.6 and see if it is stable @ or below 1.5 because with the voltage fluctuations my board gives I'd probably hitting 1.6+ at times if I go any higher on voltages. I hit 1.57 already at 1.5. I'm actually considering refunding this board because I have a ungodly long POST time of 20+ seconds along with a mysterious mouse issue(jumpy and erratic).

EDIT: LOL Fixed the mouse issue I think. Apparently, this board comes with USB1.0 and puts that were you want to hook up a mouse, next to the single PS/2 port.

My BIOS just list VDDNB and that's the only thing related to NB I get outside of chipset. It says it's controlled by the CPU and when I go to 1.4 it turns red. I have no idea why you so many NB voltages. Your manual probably left out any mention of them and what they did right? I love how they tell you what all the things you know are and forget to put the things you don't know in the damn manual. -_-
Edited by Rookie1337 - 12/28/10 at 10:09pm

CPUGraphicsRAMHard Drive
Intel Core m3-6Y30 Intel HD515 8GB 1866DDR3L Micron M600 MTFDDAV256MBF M.2, 256 GB
CoolingOSOSMonitor
Fanless Win10 Home x64 Kubuntu 16.04 (requires Linux kernel 4.5/4.6) 13.3 inch 16:9, 1920x1080 pixel, AU Optronics A...
CPUMotherboardGraphicsRAM
AthlonIIX4 640 3.62GHz (250x14.5) 2.5GHz NB Asus M4A785TD-M EVO MSI GTX275 (Stock 666) 8GBs of GSkill 1600
RAMHard DriveHard DriveHard Drive
4GBs of Adata 1333 Kingston HyperX 3k 120GB WD Caviar Black 500GB Hitachi Deskstar 1TB
Optical DriveCoolingOSOS
LG 8X BDR (WHL08S20) Cooler Master Hyper 212+ Kubuntu x64 Windows 7 x64
OSMonitorPowerCase
Bodhi Linux x64 Acer G215H (1920x1080) Seasonic 520 HAF912
CPUMotherboardGraphicsRAM
N450 1.8GHz AC and 1.66GHz batt ASUS proprietary for 1001P GMA3150 (can play bluray now!?) 1GB DDR2
Hard DriveOptical DriveOSOS
160GB LGLHDLBDRE32X Bodhi Linux Fedora LXDE
OSOSMonitorKeyboard
Kubuntu SLAX 1280x600 + Dell 15inch Excellent!
PowerCase
6 cells=6-12hrs and a charger 1001P MU17 Black
  hide details
Reply

CPUGraphicsRAMHard Drive
Intel Core m3-6Y30 Intel HD515 8GB 1866DDR3L Micron M600 MTFDDAV256MBF M.2, 256 GB
CoolingOSOSMonitor
Fanless Win10 Home x64 Kubuntu 16.04 (requires Linux kernel 4.5/4.6) 13.3 inch 16:9, 1920x1080 pixel, AU Optronics A...
CPUMotherboardGraphicsRAM
AthlonIIX4 640 3.62GHz (250x14.5) 2.5GHz NB Asus M4A785TD-M EVO MSI GTX275 (Stock 666) 8GBs of GSkill 1600
RAMHard DriveHard DriveHard Drive
4GBs of Adata 1333 Kingston HyperX 3k 120GB WD Caviar Black 500GB Hitachi Deskstar 1TB
Optical DriveCoolingOSOS
LG 8X BDR (WHL08S20) Cooler Master Hyper 212+ Kubuntu x64 Windows 7 x64
OSMonitorPowerCase
Bodhi Linux x64 Acer G215H (1920x1080) Seasonic 520 HAF912
CPUMotherboardGraphicsRAM
N450 1.8GHz AC and 1.66GHz batt ASUS proprietary for 1001P GMA3150 (can play bluray now!?) 1GB DDR2
Hard DriveOptical DriveOSOS
160GB LGLHDLBDRE32X Bodhi Linux Fedora LXDE
OSOSMonitorKeyboard
Kubuntu SLAX 1280x600 + Dell 15inch Excellent!
PowerCase
6 cells=6-12hrs and a charger 1001P MU17 Black
  hide details
Reply
post #33 of 85
Thread Starter
My computer from power button to win with Coretemp, skype and Gatherplace loaded is 31 seconds, but I have an SSD. If I was not so close to going to SLI I would get a new board, there are a ton of AMD chip-sets that OC very well from what I read. I just dont have a ton of faith in the SLI Hack or fusion yet.

My Bios turns red at 1.4 as well on the CPU and Yellow on the Ram at 1.6, but I have the corsair dominators that are 1.65v. Just to get stability I have to over-volt that.That is just recommended. 3.6 is not bad for an Athalon is what I am going to tell my self, then I will go all out once bulldozer gets here.
BullDriver
(13 items)


CPUMotherboardGraphicsRAM
FX-8350 Vishera 4.0GHz Asus 990FX Sabertooth MSI N465GTX 8gb Gskill Sniper 1600/9.9.9.25
Hard DriveOptical DriveOSMonitor
64Gb Crucial SSD(os) +1tb Baracuda SataIII Asus OEM SATA DVD RW x64 Windows 7 Home Premium 25" Hanns G
KeyboardPowerCaseMouse
Microsoft Flatty Tethered RocketFish 550w Modular Corsair 600t Logitech MX Revolution
  hide details
Reply
BullDriver
(13 items)


CPUMotherboardGraphicsRAM
FX-8350 Vishera 4.0GHz Asus 990FX Sabertooth MSI N465GTX 8gb Gskill Sniper 1600/9.9.9.25
Hard DriveOptical DriveOSMonitor
64Gb Crucial SSD(os) +1tb Baracuda SataIII Asus OEM SATA DVD RW x64 Windows 7 Home Premium 25" Hanns G
KeyboardPowerCaseMouse
Microsoft Flatty Tethered RocketFish 550w Modular Corsair 600t Logitech MX Revolution
  hide details
Reply
post #34 of 85
Just thought I'd input my frustration with my 640 too, 3.5GHz @ 1.44v is fine but any more than 3.5GHz (even with 1.5v+) will not make it stable.

I did manage to get my FSB to 250MHz for 2500MHz CPUNB @ 1.3v, memory @ 1332 7-7-7-20.

These chips may well be C3 revision but from the stories online they won't OC far under 1.5v (reaching the limits of air).

Just for a little reference my old x2 240 C2 would hit 3.85Ghz @ 1.45v (1050MHz OC), or everyday at 3.5GHz @ 1.39v, 2500MHz CPUNB at stock voltage.

CPUMotherboardGraphicsRAM
i5 2500k @ 4.5GHz 1.4v ASRock Z68 Extreme3 Gen3 MSI R9 290x Gaming 2x4GB Corsair XMS3 1600
Hard DriveHard DriveCoolingOS
Crucial BX100 250GB Toshiba 2TB Thermalright Macho 120 Rev.A Win 10 Sexy Phwoar bits
MonitorKeyboardPowerCase
LG 29UM68 (2560x1080) Logitech MK600 SuperFlower GG HX 650W FD Define R4 White Window
MouseMouse PadAudioAudio
Logitech G502 CM SWIFT-RX XXL Cheap USB DAC Epiphany Acoustics EHP-O2
Audio
AKG K612 Pro
  hide details
Reply

CPUMotherboardGraphicsRAM
i5 2500k @ 4.5GHz 1.4v ASRock Z68 Extreme3 Gen3 MSI R9 290x Gaming 2x4GB Corsair XMS3 1600
Hard DriveHard DriveCoolingOS
Crucial BX100 250GB Toshiba 2TB Thermalright Macho 120 Rev.A Win 10 Sexy Phwoar bits
MonitorKeyboardPowerCase
LG 29UM68 (2560x1080) Logitech MK600 SuperFlower GG HX 650W FD Define R4 White Window
MouseMouse PadAudioAudio
Logitech G502 CM SWIFT-RX XXL Cheap USB DAC Epiphany Acoustics EHP-O2
Audio
AKG K612 Pro
  hide details
Reply
post #35 of 85
Mines at 3.6GHz you WILL need about 1.5v
post #36 of 85
just so you guys know, [CPU-NB] voltage is connected to the IMC northbridge frequency in the memory tab in CPUz and [NB] voltage is connected to HT link for the northbridge chip on the motherboard.

[CPU-NB] max is 1.45v. i use 1.35 for up to 2600 mhz on the northbridge just fine. 1.45 is only needed if your going 2800+ which you probably wont need on the athlon.

[NB] i have it set to 1.2v. thats +.1v from stock. since the HT link is staying close to stock (around 2000 mhz) you dont need alot of extra volts here. 1.35 should be max for NB tho.

...and if the "setting" turns red in the bios dont worry. it doesnt mean its too much, just that the bios writers are warning you that its getting higher than rated (or what they think is too high), which if your cooling is on par you should be fine. i always use CPUz (which is a reading vs a setting) to see what my actual volts are cuz most boards fluctuate.
Edited by Namwons - 12/29/10 at 4:46am
post #37 of 85
"Come on you apes, you wanna live forever?" If i can hit 270 FSB on my AII X4 620 yall should be breezing @ 3.8GHz with the higher multis.
White Lightning
(13 items)

Black Thunder
(16 items)


CPUMotherboardGraphicsRAM
AMD Ryzen 7 1700X Processor  ASUS ROG Crosshair VI Hero (WI-FI AC) EVGA GeForce GTX 1050 Ti SSC GAMING ACX 3.0  Corsair Vengeance 16GB DDR4 3200 White LED
Hard DriveHard DriveOptical DriveCooling
Crucial MX300 525GB M.2 SSD  Toshiba X300 4TB Desktop 3.5  LG WH16NS40 Super Multi Blue 16x Blu-ray Disc  Corsair Hydro Series H110i Extreme Performance...
CoolingOSMonitorPower
Corsair Corsair Air Series AF140 LED Quiet Edi... Windows 10 Pro AOC 2757 27" 1080p IPS Monitor  Seasonic SS-760XP2 Platinum
Case
Cooler Master Mastercase Pro 5
CPUMotherboardGraphicsRAM
AMD FX-8320E @ 4.1GHz Asrock 970M Pro3 mATX XFX Radeon RX 460 4 GB GDDR5 PCI Express 3.0 Gr... PNY Anarchy 16GB Kit (2x8GB) DDR3 1866MHz
Hard DriveOptical DriveCoolingOS
SAMSUNG 850 EVO 2.5" 250GB SAMSUNG DVD Writer SH-224FB Scythe Samurai ZZ Rev.B CPU Cooler Windows 7 Pro SP1
MonitorKeyboardPowerCase
AOC 27" I2757FH IPS LED HD Monitor Zalman ZM-K200M USB Keyboard EVGA 500W 80 PLUS Certified Power Supply Thermaltake Urban S1 Mini Tower Computer Case
MouseMouse PadAudioOther
Zalman ZM-400M USB Mouse Jeecoo Mouse Pad 320x270x3mm Non-slip Rubber Ba... Z313 Multimedia Speaker System  AzureWave Broadcom BCM94352HMB/BCM94352 802.11/...
CPUMotherboardRAMHard Drive
Marvell 6282 Processor( 1.60GHz 256KB) Marvell 88F6282 SoC 256MB DDR3 1600 MHz Seagate Barracuda Green 2TB SATA 6Gb/s 64MB
OS
LenovoEMC LifeLine 4.0
  hide details
Reply
White Lightning
(13 items)

Black Thunder
(16 items)


CPUMotherboardGraphicsRAM
AMD Ryzen 7 1700X Processor  ASUS ROG Crosshair VI Hero (WI-FI AC) EVGA GeForce GTX 1050 Ti SSC GAMING ACX 3.0  Corsair Vengeance 16GB DDR4 3200 White LED
Hard DriveHard DriveOptical DriveCooling
Crucial MX300 525GB M.2 SSD  Toshiba X300 4TB Desktop 3.5  LG WH16NS40 Super Multi Blue 16x Blu-ray Disc  Corsair Hydro Series H110i Extreme Performance...
CoolingOSMonitorPower
Corsair Corsair Air Series AF140 LED Quiet Edi... Windows 10 Pro AOC 2757 27" 1080p IPS Monitor  Seasonic SS-760XP2 Platinum
Case
Cooler Master Mastercase Pro 5
CPUMotherboardGraphicsRAM
AMD FX-8320E @ 4.1GHz Asrock 970M Pro3 mATX XFX Radeon RX 460 4 GB GDDR5 PCI Express 3.0 Gr... PNY Anarchy 16GB Kit (2x8GB) DDR3 1866MHz
Hard DriveOptical DriveCoolingOS
SAMSUNG 850 EVO 2.5" 250GB SAMSUNG DVD Writer SH-224FB Scythe Samurai ZZ Rev.B CPU Cooler Windows 7 Pro SP1
MonitorKeyboardPowerCase
AOC 27" I2757FH IPS LED HD Monitor Zalman ZM-K200M USB Keyboard EVGA 500W 80 PLUS Certified Power Supply Thermaltake Urban S1 Mini Tower Computer Case
MouseMouse PadAudioOther
Zalman ZM-400M USB Mouse Jeecoo Mouse Pad 320x270x3mm Non-slip Rubber Ba... Z313 Multimedia Speaker System  AzureWave Broadcom BCM94352HMB/BCM94352 802.11/...
CPUMotherboardRAMHard Drive
Marvell 6282 Processor( 1.60GHz 256KB) Marvell 88F6282 SoC 256MB DDR3 1600 MHz Seagate Barracuda Green 2TB SATA 6Gb/s 64MB
OS
LenovoEMC LifeLine 4.0
  hide details
Reply
post #38 of 85
Thread Starter
The night is over and prime ran for 7 hours without incident. I am going to 3.75 later today.
BullDriver
(13 items)


CPUMotherboardGraphicsRAM
FX-8350 Vishera 4.0GHz Asus 990FX Sabertooth MSI N465GTX 8gb Gskill Sniper 1600/9.9.9.25
Hard DriveOptical DriveOSMonitor
64Gb Crucial SSD(os) +1tb Baracuda SataIII Asus OEM SATA DVD RW x64 Windows 7 Home Premium 25" Hanns G
KeyboardPowerCaseMouse
Microsoft Flatty Tethered RocketFish 550w Modular Corsair 600t Logitech MX Revolution
  hide details
Reply
BullDriver
(13 items)


CPUMotherboardGraphicsRAM
FX-8350 Vishera 4.0GHz Asus 990FX Sabertooth MSI N465GTX 8gb Gskill Sniper 1600/9.9.9.25
Hard DriveOptical DriveOSMonitor
64Gb Crucial SSD(os) +1tb Baracuda SataIII Asus OEM SATA DVD RW x64 Windows 7 Home Premium 25" Hanns G
KeyboardPowerCaseMouse
Microsoft Flatty Tethered RocketFish 550w Modular Corsair 600t Logitech MX Revolution
  hide details
Reply
post #39 of 85
I think the reason we're struggling has more to do with the board than the chip at this point. I remember years ago when I had my 6400windsor and reading about the infamous 250 reference wall. I guess I had hoped they'd overcome that with time but it's not looking good.

I've dropped back down to 3.6 at 1.45 and currently one hour into p95. Didn't make it this far with 3.75 and 1.5 volts because about 30mins in one or more core began to fall 1-2 tests behind. It was weird.

UPDATE: 2hrs in and now all the cores are on different tests. Am I unstable or is this OK? And if anyone wants to state with absolute certainty what VDDNB is that would help us out.
Edited by Rookie1337 - 12/29/10 at 10:19am

CPUGraphicsRAMHard Drive
Intel Core m3-6Y30 Intel HD515 8GB 1866DDR3L Micron M600 MTFDDAV256MBF M.2, 256 GB
CoolingOSOSMonitor
Fanless Win10 Home x64 Kubuntu 16.04 (requires Linux kernel 4.5/4.6) 13.3 inch 16:9, 1920x1080 pixel, AU Optronics A...
CPUMotherboardGraphicsRAM
AthlonIIX4 640 3.62GHz (250x14.5) 2.5GHz NB Asus M4A785TD-M EVO MSI GTX275 (Stock 666) 8GBs of GSkill 1600
RAMHard DriveHard DriveHard Drive
4GBs of Adata 1333 Kingston HyperX 3k 120GB WD Caviar Black 500GB Hitachi Deskstar 1TB
Optical DriveCoolingOSOS
LG 8X BDR (WHL08S20) Cooler Master Hyper 212+ Kubuntu x64 Windows 7 x64
OSMonitorPowerCase
Bodhi Linux x64 Acer G215H (1920x1080) Seasonic 520 HAF912
CPUMotherboardGraphicsRAM
N450 1.8GHz AC and 1.66GHz batt ASUS proprietary for 1001P GMA3150 (can play bluray now!?) 1GB DDR2
Hard DriveOptical DriveOSOS
160GB LGLHDLBDRE32X Bodhi Linux Fedora LXDE
OSOSMonitorKeyboard
Kubuntu SLAX 1280x600 + Dell 15inch Excellent!
PowerCase
6 cells=6-12hrs and a charger 1001P MU17 Black
  hide details
Reply

CPUGraphicsRAMHard Drive
Intel Core m3-6Y30 Intel HD515 8GB 1866DDR3L Micron M600 MTFDDAV256MBF M.2, 256 GB
CoolingOSOSMonitor
Fanless Win10 Home x64 Kubuntu 16.04 (requires Linux kernel 4.5/4.6) 13.3 inch 16:9, 1920x1080 pixel, AU Optronics A...
CPUMotherboardGraphicsRAM
AthlonIIX4 640 3.62GHz (250x14.5) 2.5GHz NB Asus M4A785TD-M EVO MSI GTX275 (Stock 666) 8GBs of GSkill 1600
RAMHard DriveHard DriveHard Drive
4GBs of Adata 1333 Kingston HyperX 3k 120GB WD Caviar Black 500GB Hitachi Deskstar 1TB
Optical DriveCoolingOSOS
LG 8X BDR (WHL08S20) Cooler Master Hyper 212+ Kubuntu x64 Windows 7 x64
OSMonitorPowerCase
Bodhi Linux x64 Acer G215H (1920x1080) Seasonic 520 HAF912
CPUMotherboardGraphicsRAM
N450 1.8GHz AC and 1.66GHz batt ASUS proprietary for 1001P GMA3150 (can play bluray now!?) 1GB DDR2
Hard DriveOptical DriveOSOS
160GB LGLHDLBDRE32X Bodhi Linux Fedora LXDE
OSOSMonitorKeyboard
Kubuntu SLAX 1280x600 + Dell 15inch Excellent!
PowerCase
6 cells=6-12hrs and a charger 1001P MU17 Black
  hide details
Reply
post #40 of 85
Dude if you can't ATLEAST manage 5 runs of Intel Burn Test with all RAM tested then it's not stable. Prime95 sucks....

Simply getting CPU-Z of high clocks is no good at all, stability is key and with your heat sink it aint going to happen.

I was at 3.6Ghz Intel Burn Test stable with 1.5v under a full custom water cooling loop and I couldn't get it any higher.
