Asrock P67 Extreme4 motherboard - Extreme Cost Performance 4 you!

post #1 of 18
Thread Starter
ASRock > Products > P67 Extreme4

BOX



CONTENTS



MOBO



FEATURES







TEST SETUP
i7 2600K at 4.5GHz, Vcore offset +0.01V, push pull TRUE120, ambient air
Asrock Extreme4 mobo
Asus GTX460 TOP clocked at 900-2000
Seventeam 850W PSU
Win 7 x64



PLAY PLAY



3D11
Physics Score@4.5Ghz (CPU score) is already 11117!
Result - P4163 3DMarks





CRUNCHING






FEATURES IN WORDS

Massive heatsinks
All solid Jap caps
Power/Reset/Clr CMOS buttons available - large, well positioned with LED
Incredibly well featured - 8 SATA, IDE, FDC, infra-red onboard
Onboard Debug LED
7 slots! Supports SLI/Crossfire at 16x (single), 8x8 (dual), 8x8x4 (triple) on a budget mobo!
Relatively spacious between CPU and RAM
Standard ATX despite the innumerable features
Good retail bundle with USB 3.0 front port box
Unigue feature, 2 CPU fan headers - 1 x 4 pin, 1 x 3 pin
LGA775 mounting holes
Pleasing POST chirp instead of the usual flat beep
Detailed UEFI BIOS with 3 user named setting save slots
S3 sleep and resume works great
Very good CPU overclocking options
- 3 ways to set Vcore - Auto, Manual - fixed or offset
- fully adjustable power throttle - both short and long duration settings
- 5 levels of Vdroop control
BIOS P1.40 has the internal CPU PLL fix for higher o'cing

At present, this is probably the most competitive and capable mobo in its price category even officialy supporting Quad SLI and Crossfire. For a new product on the new LGA1155 platform, this is the most quirk free mobo I have tested so far - no cold boots/reboots/BIOS auto-recovery and no need to clear CMOS so far. In fact, for once I had little improvement suggestions to feedback to the mobo maker and its BIOS team.

Highly recommended - for those on a budget and also for those who are not, my personal favourite mobo so far.
Tick Tac Tock!
(12 items)


CPUMotherboardGraphicsRAM
AMD | Intel Asrock | Asus AMD 32GB Vengeance Pro DDR3-2666
Hard DriveOptical DriveCoolingOS
IntelSSD Pioneer | Samsung NiCu Heatkiller 3.0 | 655 | MicroRes | GTX360 Win7 x64
MonitorKeyboardPowerCase
1920x1200 Logitech Corsair-Enermax Open air MoBoX | MSI Bench 3G
  hide details
Reply
Tick Tac Tock!
(12 items)


CPUMotherboardGraphicsRAM
AMD | Intel Asrock | Asus AMD 32GB Vengeance Pro DDR3-2666
Hard DriveOptical DriveCoolingOS
IntelSSD Pioneer | Samsung NiCu Heatkiller 3.0 | 655 | MicroRes | GTX360 Win7 x64
MonitorKeyboardPowerCase
1920x1200 Logitech Corsair-Enermax Open air MoBoX | MSI Bench 3G
  hide details
Reply
post #2 of 18
looks like a great mobo, hard to beat it for the price
post #3 of 18
Thanks for the pictures, it's a good looking board. I'll be picking up either the Extreme4 or 6 along with a 2500k when I get a chance Depends on how a few things play out

CPUGraphicsRAMHard Drive
Intel Core i7 6700HQ nVidia GTX 965m 16GB DDR4-2133 120GB M.2.SSD
Hard DriveOSMonitorKeyboard
480GB Crucial M500 Windows 10 Pro Dell Ultrasharp u2713hm Corsair Vengeance K70
MouseAudio
Logitech G600 Creative T20
  hide details
Reply

CPUGraphicsRAMHard Drive
Intel Core i7 6700HQ nVidia GTX 965m 16GB DDR4-2133 120GB M.2.SSD
Hard DriveOSMonitorKeyboard
480GB Crucial M500 Windows 10 Pro Dell Ultrasharp u2713hm Corsair Vengeance K70
MouseAudio
Logitech G600 Creative T20
  hide details
Reply
post #4 of 18
How long does it take to boot, is it a big improvement over the old Bios? Could you measure how many seconds to the pleasing beep sound, how many till the OS starts to load?
2500k
(13 items)


CPUMotherboardGraphicsRAM
2500K asrock z68 pro3 Intel HD3000 8 GB G.skill 1.25v
Hard DriveOSMonitorPower
Intel postville 80GB Windows 7 64bit S27A950D Seasonic x-400 fanless
CaseMouse
Lian Li PC-A77FR HP Voodoo DNA
  hide details
Reply
2500k
(13 items)


CPUMotherboardGraphicsRAM
2500K asrock z68 pro3 Intel HD3000 8 GB G.skill 1.25v
Hard DriveOSMonitorPower
Intel postville 80GB Windows 7 64bit S27A950D Seasonic x-400 fanless
CaseMouse
Lian Li PC-A77FR HP Voodoo DNA
  hide details
Reply
post #5 of 18
@MacClipper

Might be nice mobo but it´s kind a hard to tell because your bandwidth is exceeded at Photobucket so no pictures is shown.
The Blue Beast
(13 items)


CPUMotherboardGraphicsRAM
Core i7-2600K cooled by Heatkiller Rev 3.0 LT ASUS P8Z68 Deluxe EVGA GTX 580 SC in SLI cooled by Koolance VID-N... 2x4GB G Skill RipjawsX 1600C8
Hard DriveOptical DriveOSMonitor
Intel SSD 510 120GB / 250GB + WD Black Caviar 1TB Samsung DVD Win 7 64-bit Samsung 2443BW @ 1920x1200
PowerCase
Corsair HX850 Lian Li PC-343B
  hide details
Reply
The Blue Beast
(13 items)


CPUMotherboardGraphicsRAM
Core i7-2600K cooled by Heatkiller Rev 3.0 LT ASUS P8Z68 Deluxe EVGA GTX 580 SC in SLI cooled by Koolance VID-N... 2x4GB G Skill RipjawsX 1600C8
Hard DriveOptical DriveOSMonitor
Intel SSD 510 120GB / 250GB + WD Black Caviar 1TB Samsung DVD Win 7 64-bit Samsung 2443BW @ 1920x1200
PowerCase
Corsair HX850 Lian Li PC-343B
  hide details
Reply
post #6 of 18
Thread Starter
Woohoo, photos trickling back liao so view them while you can before PhotoKickTheBucket clamps down again.
Tick Tac Tock!
(12 items)


CPUMotherboardGraphicsRAM
AMD | Intel Asrock | Asus AMD 32GB Vengeance Pro DDR3-2666
Hard DriveOptical DriveCoolingOS
IntelSSD Pioneer | Samsung NiCu Heatkiller 3.0 | 655 | MicroRes | GTX360 Win7 x64
MonitorKeyboardPowerCase
1920x1200 Logitech Corsair-Enermax Open air MoBoX | MSI Bench 3G
  hide details
Reply
Tick Tac Tock!
(12 items)


CPUMotherboardGraphicsRAM
AMD | Intel Asrock | Asus AMD 32GB Vengeance Pro DDR3-2666
Hard DriveOptical DriveCoolingOS
IntelSSD Pioneer | Samsung NiCu Heatkiller 3.0 | 655 | MicroRes | GTX360 Win7 x64
MonitorKeyboardPowerCase
1920x1200 Logitech Corsair-Enermax Open air MoBoX | MSI Bench 3G
  hide details
Reply
post #7 of 18
Nice board, I was looking at that one as well

in for more results,

What is the power solution on that board ?
Leviathan
(27 items)


CPUMotherboardGraphicsGraphics
Intel i7 3930k MSI X79A-GD65 (8D) eVGA (SC) GTX Titan  eVGA (SC) GTX Titan
RAMHard DriveHard DriveHard Drive
Team Group 16GB Team Extreme 2400MHz 9-11-11-28 1T Samsung 128GB 830 Samsung 128GB 830 OCZ 120GB Solid 3
Hard DriveHard DriveCoolingCooling
OCZ 120GB Solid 3 Western Digital 640GB Black  4x Coolgate Quad 120mm Ultimate Heat Exchanger ... EK Supremacy Universal CPU Liquid Cooling Block
CoolingCoolingCoolingCooling
2x EK Geforce GTX Titan VGA Liquid Cooling Bloc... EK DDC X-RES Top 140 - Acetal w/250mm tube exte... EK DDC X-RES Top 140 - Acetal  8x Corsair Air Series SP120 Quiet Edition CO-90...
CoolingCoolingOSMonitor
7x Xigmatek AOS (Aeronautical Oil System Bearin... 8x Yate Loon 120 x 38mm Low Speed Silent Case F... 7 64 bit Crossover
KeyboardPowerCaseMouse
Razor Black Widow Ultimant 2013 Corsair AX1200 CaseLabs TH10 Black TT Level 10M
Mouse PadAudio
TT Landon  Creative 3D Recon
  hide details
Reply
Leviathan
(27 items)


CPUMotherboardGraphicsGraphics
Intel i7 3930k MSI X79A-GD65 (8D) eVGA (SC) GTX Titan  eVGA (SC) GTX Titan
RAMHard DriveHard DriveHard Drive
Team Group 16GB Team Extreme 2400MHz 9-11-11-28 1T Samsung 128GB 830 Samsung 128GB 830 OCZ 120GB Solid 3
Hard DriveHard DriveCoolingCooling
OCZ 120GB Solid 3 Western Digital 640GB Black  4x Coolgate Quad 120mm Ultimate Heat Exchanger ... EK Supremacy Universal CPU Liquid Cooling Block
CoolingCoolingCoolingCooling
2x EK Geforce GTX Titan VGA Liquid Cooling Bloc... EK DDC X-RES Top 140 - Acetal w/250mm tube exte... EK DDC X-RES Top 140 - Acetal  8x Corsair Air Series SP120 Quiet Edition CO-90...
CoolingCoolingOSMonitor
7x Xigmatek AOS (Aeronautical Oil System Bearin... 8x Yate Loon 120 x 38mm Low Speed Silent Case F... 7 64 bit Crossover
KeyboardPowerCaseMouse
Razor Black Widow Ultimant 2013 Corsair AX1200 CaseLabs TH10 Black TT Level 10M
Mouse PadAudio
TT Landon  Creative 3D Recon
  hide details
Reply
post #8 of 18
Great review and pics! I just got mine running today! 4.5GHz was my most stable using the auto OC. Would like to find the 1.40 BIOS and try some other options.
Main Rig
(13 items)


CPUMotherboardGraphicsRAM
2600k @ 4.8GHz Asrock Extreme 4 GTX570 8GB G.Skill Ripjaws X 1600
Hard DriveOptical DriveOSMonitor
Sandforce SSD (Microcenter) LG BD Reader Win7 Ultimate x64 I-Inc 28" 1920x1600
PowerCaseMouse
Corsair HX750W Cooler Master HAF 912 Logitech MX518
  hide details
Reply
Main Rig
(13 items)


CPUMotherboardGraphicsRAM
2600k @ 4.8GHz Asrock Extreme 4 GTX570 8GB G.Skill Ripjaws X 1600
Hard DriveOptical DriveOSMonitor
Sandforce SSD (Microcenter) LG BD Reader Win7 Ultimate x64 I-Inc 28" 1920x1600
PowerCaseMouse
Corsair HX750W Cooler Master HAF 912 Logitech MX518
  hide details
Reply
post #9 of 18
Hey Mac, didn't know you had an account at OCN too.

Lovely board, great PCI slot layout.

I'm assuming it's an 8+2 power phase design?
Baldy's Slave
(14 items)


CPUMotherboardGraphicsRAM
|Intel Core i5 4690K| |ASUS Z97-A| |Zotac GTX 660 2GB| |G.SKILL Ripjaws X Series 16GB (2 x 8GB) DDR3 1...
Hard DriveCoolingMonitorPower
|Samsung 840 EVO 250GB SSD| |CM Hyper 212 EVO| |Dell E2414Hx| |Rosewill Capstone 650W 80PLUS Gold|
Case
|Fractal Design Core 3500|
  hide details
Reply
Baldy's Slave
(14 items)


CPUMotherboardGraphicsRAM
|Intel Core i5 4690K| |ASUS Z97-A| |Zotac GTX 660 2GB| |G.SKILL Ripjaws X Series 16GB (2 x 8GB) DDR3 1...
Hard DriveCoolingMonitorPower
|Samsung 840 EVO 250GB SSD| |CM Hyper 212 EVO| |Dell E2414Hx| |Rosewill Capstone 650W 80PLUS Gold|
Case
|Fractal Design Core 3500|
  hide details
Reply
post #10 of 18
hey bros i just got this board and doing 5.3ghz temps are 70c
