project overhaul

post #1 of 9
Thread Starter
Oh hello,

long time lurker, first time thread maker. i'm revamping my current build (watercooled i7 920 w/ Apogee XT, 2x XFX ATi 5850 x-fire (non-reference >_<), XFX 9600GT (PhysX card), for case modding and soon to include all 3 video cards in the watercooling.

possibly expanding to include memory in the loop at some point, keeping my options open for future development with this build. i currently only have one pump, at this point I'm strongly considering expanding to two pumps just because of the size of this 1 loop.

My build is somewhat inspired by this picture that I stumbled upon a while back:

as it is the case that I have. If anyone knows who that case belongs to, please give them my thanks.


Materials

waterblocks & heatsinks
CPU: Apogee XT


GPU 1&2: MCW80

with Enzotech Forged Copper VGA Memory Heatsinks

GPU 3 (PhysX GPU): EK-FC9600 SLI High Performance Water Block - Acetal



heat exchangers
1x Swiftech MCR420 "Quiet Power"

I managed to get this guy as an open box item for newegg for only $45, about 10-15 less than the 320 rads go for. I couldn't pass the deal when I saw it.

2x Swiftech MCR320 "Quiet Power"


pump
Koolance PMP-300

considering buying a 2nd to install in series in the loop. thoughts?


other (some tentative) case modifications
spraying case interior
cable management aka general cable cleanup
handle on top
bottom intake fan(s)?
stand?
side window (with 220mm intake fan)
more I can't think of ATM

constructive criticism/ideas are welcomed.

I apologize in advance if any of the pictures that I end up taking don't come out amazingly, I will likely end up using the camera on my G2 for most (if not all) of them.
