EK-DDC and MCP35x - Page 2

post #11 of 46
I'll just leave this here:

System
(13 items)


CPUMotherboardGraphicsRAM
i7-2500k Asrock P67 Extreme6 HD 5870 Eyefinity 6 x2 Gigabyte GV-R5876P-2GD-B G.Skill Ripjaws 1333 4GB x 4
Hard DriveOSMonitorKeyboard
OCZ RevoDrive x2 240GB Windows 7 x64 Ultimate 6x 23" Samsung MD230 (MD230x6) Razer BlackWidow Ultimate
PowerCaseMouseMouse Pad
Antech HCP-1200 Little Devil PC-V8 Logitech G700 Belkin Gel
  hide details
Reply
System
(13 items)


CPUMotherboardGraphicsRAM
i7-2500k Asrock P67 Extreme6 HD 5870 Eyefinity 6 x2 Gigabyte GV-R5876P-2GD-B G.Skill Ripjaws 1333 4GB x 4
Hard DriveOSMonitorKeyboard
OCZ RevoDrive x2 240GB Windows 7 x64 Ultimate 6x 23" Samsung MD230 (MD230x6) Razer BlackWidow Ultimate
PowerCaseMouseMouse Pad
Antech HCP-1200 Little Devil PC-V8 Logitech G700 Belkin Gel
  hide details
Reply
post #12 of 46
Quote:
Originally Posted by Martinm210;12301387
FYI, there is more to the difference in the 3.25 vs 35X than PWM control as well.
Quote:
Originally Posted by Chunky_Chimp;12301419
Such as? thinking.gif
Quote:
Originally Posted by Skinnee
Moving to the MCP35X and DDC3.25 comparison, we really start to see some differences. The MCP35X has a nice round curve in the higher flow ranges and starts to flatten out around 1.75GPM, where the DDC3.25 (also known as the Koolance PMP-400) has a much steeper curve. You will see exactly what this means to your loop flow rates in the next section, but what this means in Lehman’s terms is that the MCP35X has a PQ range that excels from high to low restriction and the DDC3.25 does better in high restriction loops. Subtle differences, but the differences are definitely there.

http://skinneelabs.com/swiftech-mcp35x/3/
System
(13 items)


CPUMotherboardGraphicsRAM
i7-2500k Asrock P67 Extreme6 HD 5870 Eyefinity 6 x2 Gigabyte GV-R5876P-2GD-B G.Skill Ripjaws 1333 4GB x 4
Hard DriveOSMonitorKeyboard
OCZ RevoDrive x2 240GB Windows 7 x64 Ultimate 6x 23" Samsung MD230 (MD230x6) Razer BlackWidow Ultimate
PowerCaseMouseMouse Pad
Antech HCP-1200 Little Devil PC-V8 Logitech G700 Belkin Gel
  hide details
Reply
System
(13 items)


CPUMotherboardGraphicsRAM
i7-2500k Asrock P67 Extreme6 HD 5870 Eyefinity 6 x2 Gigabyte GV-R5876P-2GD-B G.Skill Ripjaws 1333 4GB x 4
Hard DriveOSMonitorKeyboard
OCZ RevoDrive x2 240GB Windows 7 x64 Ultimate 6x 23" Samsung MD230 (MD230x6) Razer BlackWidow Ultimate
PowerCaseMouseMouse Pad
Antech HCP-1200 Little Devil PC-V8 Logitech G700 Belkin Gel
  hide details
Reply
post #13 of 46
Quote:
Originally Posted by Chunky_Chimp;12301419
Such as? thinking.gif

Yeah, it has a different speed control curve of sorts. The pumps have circuitry that reduces RPM as restriction reduces and flow rate increases. Each pump does it a little different

Nothing that's going to make any noteworthy temperature difference, but there is some difference.
Edited by Martinm210 - 2/7/11 at 9:54pm

CPUMotherboardGraphicsRAM
3930K ASrock X79 Ext7 Evga GTX570 CORSAIR Vengeance 16GB
Hard DriveOptical DriveOSMonitor
Phoenix SSD+2TB Seagate drives ASUS DVD-RW combo Windows 7 28" Hanns-G HZ281
KeyboardPowerCaseMouse
MS Natural Corsair TX650 Danger Den Torture Rack Logitech MX518
Mouse Pad
Desk
  hide details
Reply

CPUMotherboardGraphicsRAM
3930K ASrock X79 Ext7 Evga GTX570 CORSAIR Vengeance 16GB
Hard DriveOptical DriveOSMonitor
Phoenix SSD+2TB Seagate drives ASUS DVD-RW combo Windows 7 28" Hanns-G HZ281
KeyboardPowerCaseMouse
MS Natural Corsair TX650 Danger Den Torture Rack Logitech MX518
Mouse Pad
Desk
  hide details
Reply
post #14 of 46
Quote:
Originally Posted by Martinm210;12303558
Yeah, it has a different speed control curve of sorts. The fans have circuitry that reduces RPM as restriction reduces and flow rate increases. Each pump does it a little different

That actually sounds like what goes on with Aquacomputer-branded Eheim 1046s (not sure if the normal 1046 does it); I quite like it.
Deep Blood
(16 items)


CPUMotherboardGraphicsRAM
Intel Core i7 920 D0 (Batch # 3901A240) Foxconn X58 Blood Rage (non-GTI) eVGA GeForce GTX670 2GB 6GB Corsair Dominator 1.6GHz TR3X6G1600C8D Rev 3.2
Hard DriveOptical DriveCoolingOS
Samsung SSD830 128GB / Seagate 640GB+1TB+2TB+4TB Samsung SH-S223Q 22X XTTH | OCZ Freeze | 9G1212H1011 Windows 7 Ultimate x64 SP1
MonitorKeyboardPowerCase
Dell U2410f (rev. A02) Code 104 w/O-rings + Vortex doubleshot keycaps Antec HCPP-850 CaseLabs SM8
MouseMouse PadAudioOther
Logitech G500 Sharkoon 1337 Asus Xonar DX + Swan D1080MkII08 + MXL Tempo Lifecam Cinema
  hide details
Reply
Deep Blood
(16 items)


CPUMotherboardGraphicsRAM
Intel Core i7 920 D0 (Batch # 3901A240) Foxconn X58 Blood Rage (non-GTI) eVGA GeForce GTX670 2GB 6GB Corsair Dominator 1.6GHz TR3X6G1600C8D Rev 3.2
Hard DriveOptical DriveCoolingOS
Samsung SSD830 128GB / Seagate 640GB+1TB+2TB+4TB Samsung SH-S223Q 22X XTTH | OCZ Freeze | 9G1212H1011 Windows 7 Ultimate x64 SP1
MonitorKeyboardPowerCase
Dell U2410f (rev. A02) Code 104 w/O-rings + Vortex doubleshot keycaps Antec HCPP-850 CaseLabs SM8
MouseMouse PadAudioOther
Logitech G500 Sharkoon 1337 Asus Xonar DX + Swan D1080MkII08 + MXL Tempo Lifecam Cinema
  hide details
Reply
post #15 of 46
Thread Starter
Thanks a lot all! Always very helpful biggrin.gif

Love you all!

Daetlus your post makes me wonder why EK support outright just said "No it does not fit."

After 2 days of me waiting for them to respond and they still don't even know about their own products. Fascinating.
post #16 of 46
Quote:
Originally Posted by Daetlus;12301816
I'll just leave this here:


Could you orient the two labels facing one another so that they don't show?

CPUMotherboardGraphicsRAM
i7 860 MSI P55-GD 85 PNY GTX 570 16 GB Muskin Blackline
Hard DriveHard DriveOptical DriveOS
WD Caviar Black 1TB Crucial SDD some LG SATA thing 7 64
MonitorKeyboardPowerCase
Dell U2311H CM Quickfire red SeaSonic X-650 Lian Li PC-B10
MouseMouse PadAudio
Cm spawn Artisan Hayate HiFiMan HE-500
  hide details
Reply

CPUMotherboardGraphicsRAM
i7 860 MSI P55-GD 85 PNY GTX 570 16 GB Muskin Blackline
Hard DriveHard DriveOptical DriveOS
WD Caviar Black 1TB Crucial SDD some LG SATA thing 7 64
MonitorKeyboardPowerCase
Dell U2311H CM Quickfire red SeaSonic X-650 Lian Li PC-B10
MouseMouse PadAudio
Cm spawn Artisan Hayate HiFiMan HE-500
  hide details
Reply
post #17 of 46
Quote:
Originally Posted by Phos;12304867
Could you orient the two labels facing one another so that they don't show?

I can't tell if that was a neatness joke, or if you were serious, though I'm assuming the first.

If so, biggrin.gif Yeah, they'll be oriented so that the labels are facing when I get to that part of the build. I just threw them on to snap the picture. Just waiting on delivery of my LittleDevil V8 to begin. Worklog for it should be fun.

If you weren't joking, then I'll have to answer your question tomorrow. The screw in locations for the pumps form the vertices of a square. I also believe that the screw locations are all an equal distance from the outside edge of the pump. This would mean that you could indeed rotate them to face any direction you would like.

If anyone wants to see more pictures on the fitting, I could snap some more.
System
(13 items)


CPUMotherboardGraphicsRAM
i7-2500k Asrock P67 Extreme6 HD 5870 Eyefinity 6 x2 Gigabyte GV-R5876P-2GD-B G.Skill Ripjaws 1333 4GB x 4
Hard DriveOSMonitorKeyboard
OCZ RevoDrive x2 240GB Windows 7 x64 Ultimate 6x 23" Samsung MD230 (MD230x6) Razer BlackWidow Ultimate
PowerCaseMouseMouse Pad
Antech HCP-1200 Little Devil PC-V8 Logitech G700 Belkin Gel
  hide details
Reply
System
(13 items)


CPUMotherboardGraphicsRAM
i7-2500k Asrock P67 Extreme6 HD 5870 Eyefinity 6 x2 Gigabyte GV-R5876P-2GD-B G.Skill Ripjaws 1333 4GB x 4
Hard DriveOSMonitorKeyboard
OCZ RevoDrive x2 240GB Windows 7 x64 Ultimate 6x 23" Samsung MD230 (MD230x6) Razer BlackWidow Ultimate
PowerCaseMouseMouse Pad
Antech HCP-1200 Little Devil PC-V8 Logitech G700 Belkin Gel
  hide details
Reply
post #18 of 46
Quote:
Originally Posted by Daetlus;12301816
I'll just leave this here:


A picture is worth a 1000 words in this case. Will have to bookmark that post as no doubt the question will be asked a few times +Rep
Roger Rabbit
(10 items)


CPUMotherboardGraphicsRAM
Core i7 3930k  Asus P9X79 Pro Evga 1080 FTW DT 16GB Corsair Vengeance LPX at 2100MHZ
MonitorMonitorKeyboardCase
Acer Predator XB271HU Dell U2715H Ducky /w Cherry Black's Phanteks Enthoo Evolv ATX TG
MouseAudio
Logitech G502 Audnist MUX-1 > HD 600's
  hide details
Reply
Roger Rabbit
(10 items)


CPUMotherboardGraphicsRAM
Core i7 3930k  Asus P9X79 Pro Evga 1080 FTW DT 16GB Corsair Vengeance LPX at 2100MHZ
MonitorMonitorKeyboardCase
Acer Predator XB271HU Dell U2715H Ducky /w Cherry Black's Phanteks Enthoo Evolv ATX TG
MouseAudio
Logitech G502 Audnist MUX-1 > HD 600's
  hide details
Reply
post #19 of 46
The DDC3.25 is a MCP355 with a different top and a small upgrade to the PCB.
The 35X is a completely new PCB, and the rotar head is a bit different over the other DDC pumps, and the base top is better.

Also all the 35* pumps are compatible to the same tops. They all have the same body and the same head room.

I'm using a couple of 35X with the EK dual top. Works perfectly.
Main system
(16 items)

Editing PC
(8 items)


CPUGraphicsGraphicsRAM
E5-1680v2 AMD FirePro D700 AMD FirePro D700 64GB 1866mhz
Hard DriveOSMonitorCase
1TB PCIE SSD OSX 10.10.x Dell U2713H Mac Pro
  hide details
Reply
Main system
(16 items)

Editing PC
(8 items)


CPUGraphicsGraphicsRAM
E5-1680v2 AMD FirePro D700 AMD FirePro D700 64GB 1866mhz
Hard DriveOSMonitorCase
1TB PCIE SSD OSX 10.10.x Dell U2713H Mac Pro
  hide details
Reply
post #20 of 46
Thread Starter
Quote:
Originally Posted by Starbuck5000;12306364
A picture is worth a 1000 words in this case. Will have to bookmark that post as no doubt the question will be asked a few times +Rep

Yep, bookmarked smile.gif
