2nd build ever-would like some tips, advice

post #1 of 15
Thread Starter
UPDATE 03/16/11: Ok so I have gotten a new motherboard. Which was actually one that was recommended here in the thread. The Asus M4A67td EVO. It seems like this will help with the VRM issue. Its a pretty nice mobo.

Problem: I was looking through the manual and to my surprise it doesnt seem to support my ram??????????????? At least in my configuration-4x4gb dimms. So I also tried to do a simple overclock to 3.8ghz which should have been cake since I have the h50 on it. and plenty of fans. But It only lasted about 1 min then bsod. changed all timings and ram freq back to auto. Only raised the cpu freq to get it to 3.8 everything else auto---- Bsod.

Im guessing ram is the prob here?

CPU-Z ID reading my ram like this.

RAM : 16384 MB DDR3 Dual Channel
RAM Speed : 668.9 MHz (3:10) @ 9-9-9-24
Slot 1 : 4096MB (10700)
Slot 1 Manufacturer : G.Skill
Slot 2 : 4096MB (10700)
Slot 2 Manufacturer : G.Skill
Slot 3 : 4096MB (10700)
Slot 3 Manufacturer : G.Skill
Slot 4 : 4096MB (10700)
Slot 4 Manufacturer : G.Skill

and even though it currently shows 3.2ghz its validating with this....



Any help appreciated...

AMD Phenom 2 1090t
16 gb GSkill Ripjaws DDR3-1600 Ram
ATI Firepro V7800 for animation and video work
ASUS M4A87TD EVO mobo
Corsair H50 sealed water cooler
Thermaltake Toughpower XT 875w psu
2 nzxt 200mm exhaust fans on top
2 120mm nzxt intake fans on side
dual 140mm intake fans on the radiator
140mm intake fan on front
All run by the fan controller on the top of the case which works rather great
Dell 24inch LED monitor
1tb WD caviar blck sata hd

NZXT Phantom case (white)










Edited by tazbo28 - 3/16/11 at 7:37pm

CPUMotherboardGraphicsRAM
Phenom II 1090t @ 3.86ghz ASUS M4A87TD EVO Firepro V7800 16gb G.Skill Ripjaws
Hard DriveOSMonitorKeyboard
1tb WD Caviar Blck Windows 7 Ultimate x64 Dell 24" LED Logitech MX3200
PowerCaseMouse
Thermaltake Toughpower XT 875w NZXT Phantom (White) Generic Dell optical
  hide details
Reply

CPUMotherboardGraphicsRAM
Phenom II 1090t @ 3.86ghz ASUS M4A87TD EVO Firepro V7800 16gb G.Skill Ripjaws
Hard DriveOSMonitorKeyboard
1tb WD Caviar Blck Windows 7 Ultimate x64 Dell 24" LED Logitech MX3200
PowerCaseMouse
Thermaltake Toughpower XT 875w NZXT Phantom (White) Generic Dell optical
  hide details
Reply
post #2 of 15
You may want to look at this thread, http://www.overclock.net/amd-motherb...hase-list.html
locate your mobo and see for yourself what we recommend as far as OC'ing.
I hate to be the one to have to say this but... well take a look for yourself.

For more info have a look at this thread as well http://www.overclock.net/amd-cpus/94...hy-choose.html
Edited by The Sandman - 3/12/11 at 7:58pm

Bruce
(14 items)

Ryzen Build
(20 items)

CPUMotherboardGraphicsRAM
FX 6350 Asus M5A99FX Pro R2.0 GTX220 G.Skill Ripjaws X F3-17000CL9D-8GBXLD 9-11-9-28...
Hard DriveHard DriveHard DriveOptical Drive
Samsung 840 Pro WD20EFRX 64M Red x4 raid 10 WD5001AALS Blk Asus DRW-24B1ST
CoolingOSMonitorKeyboard
Hyper 212 Evo R2 Windows Server 2008 R2 Standard Asus  Logitech MK300
PowerCase
Corsair HX500 Corsair 330R Titainium
CPUMotherboardGraphicsRAM
R7 1800x Crosshair VI Hero Diamond 7970 GSkill FlareX F4-3200C14D-16GFX
Hard DriveHard DriveHard DriveHard Drive
Samsung 960 EVO NVMe Samsung 840 SSD Corsair GT SSD WD 2TB Black
Hard DriveCoolingCoolingCooling
WD 4TB Red EK-FB Asus C6H Monoblock XSPC GPU Razor WB XSPC RX 360
CoolingCoolingCoolingCooling
XSPC RS 360 XSPC EX140 D5 Vario Gentle Typhoon AP-15 1850 rpm
OSMonitorPowerCase
Win 10 Pro Asus VE248H x2 EVGA 850 G2 Xigmatek Elysium
  hide details
Reply

Bruce
(14 items)

Ryzen Build
(20 items)

CPUMotherboardGraphicsRAM
FX 6350 Asus M5A99FX Pro R2.0 GTX220 G.Skill Ripjaws X F3-17000CL9D-8GBXLD 9-11-9-28...
Hard DriveHard DriveHard DriveOptical Drive
Samsung 840 Pro WD20EFRX 64M Red x4 raid 10 WD5001AALS Blk Asus DRW-24B1ST
CoolingOSMonitorKeyboard
Hyper 212 Evo R2 Windows Server 2008 R2 Standard Asus  Logitech MK300
PowerCase
Corsair HX500 Corsair 330R Titainium
CPUMotherboardGraphicsRAM
R7 1800x Crosshair VI Hero Diamond 7970 GSkill FlareX F4-3200C14D-16GFX
Hard DriveHard DriveHard DriveHard Drive
Samsung 960 EVO NVMe Samsung 840 SSD Corsair GT SSD WD 2TB Black
Hard DriveCoolingCoolingCooling
WD 4TB Red EK-FB Asus C6H Monoblock XSPC GPU Razor WB XSPC RX 360
CoolingCoolingCoolingCooling
XSPC RS 360 XSPC EX140 D5 Vario Gentle Typhoon AP-15 1850 rpm
OSMonitorPowerCase
Win 10 Pro Asus VE248H x2 EVGA 850 G2 Xigmatek Elysium
  hide details
Reply
post #3 of 15
What kinda gpu u got in that.
The Rigster
(15 items)


CPUMotherboardGraphicsRAM
Amd FX-6100 Black Edition @4.7Ghz Gigabyte Evga GTX 560ti 1GB 8 gigs ddr3
Hard DriveOptical DriveCoolingOS
1 TB Lg cooler master Win 7 ultimate 64bit
MonitorKeyboardPowerCase
23' acer 1920x1080 indland lepa 500watt Storm Scout
MouseMouse PadAudio
inland Giaint counter strike source pad 5.1 logitech
  hide details
Reply
The Rigster
(15 items)


CPUMotherboardGraphicsRAM
Amd FX-6100 Black Edition @4.7Ghz Gigabyte Evga GTX 560ti 1GB 8 gigs ddr3
Hard DriveOptical DriveCoolingOS
1 TB Lg cooler master Win 7 ultimate 64bit
MonitorKeyboardPowerCase
23' acer 1920x1080 indland lepa 500watt Storm Scout
MouseMouse PadAudio
inland Giaint counter strike source pad 5.1 logitech
  hide details
Reply
post #4 of 15
Oh boy...... 1090T + this mobo
Again

I smell fire
Keep it at stock, and begin undervolting

Swap that mobo when you can... far from safely x6 ready
Edited by xd_1771 - 3/12/11 at 8:44pm
post #5 of 15
Thread Starter
Awe man is this mobo a possible fire hazard? had good reviews on newegg. and it wasnt too expensive which is why i got it. Or did someone just up the voltage to high on a defective board?

also, Im running the Firepro V7800 like i said in the first post. Its a workstation gpu mainly for cad and animation related work. I do video editing in premier and use maya 2011 so its great.

the comp seems to be running flawlessly right now. temps are great.

CPUMotherboardGraphicsRAM
Phenom II 1090t @ 3.86ghz ASUS M4A87TD EVO Firepro V7800 16gb G.Skill Ripjaws
Hard DriveOSMonitorKeyboard
1tb WD Caviar Blck Windows 7 Ultimate x64 Dell 24" LED Logitech MX3200
PowerCaseMouse
Thermaltake Toughpower XT 875w NZXT Phantom (White) Generic Dell optical
  hide details
Reply

CPUMotherboardGraphicsRAM
Phenom II 1090t @ 3.86ghz ASUS M4A87TD EVO Firepro V7800 16gb G.Skill Ripjaws
Hard DriveOSMonitorKeyboard
1tb WD Caviar Blck Windows 7 Ultimate x64 Dell 24" LED Logitech MX3200
PowerCaseMouse
Thermaltake Toughpower XT 875w NZXT Phantom (White) Generic Dell optical
  hide details
Reply
post #6 of 15
Thread Starter
so am i sol with this board then? I guess i just ate some money there. Wish these types of recommendations would appear on newegg. I went through the reviews and really didnt hear these types of issues. It says it supports phenom II processors so why wouldnt MSI cut some more cash to do the proper testing. If this is case then I may just have to suck it up and leave it stock. But i was hoping to do something to it, especially since i got the h50.

CPUMotherboardGraphicsRAM
Phenom II 1090t @ 3.86ghz ASUS M4A87TD EVO Firepro V7800 16gb G.Skill Ripjaws
Hard DriveOSMonitorKeyboard
1tb WD Caviar Blck Windows 7 Ultimate x64 Dell 24" LED Logitech MX3200
PowerCaseMouse
Thermaltake Toughpower XT 875w NZXT Phantom (White) Generic Dell optical
  hide details
Reply

CPUMotherboardGraphicsRAM
Phenom II 1090t @ 3.86ghz ASUS M4A87TD EVO Firepro V7800 16gb G.Skill Ripjaws
Hard DriveOSMonitorKeyboard
1tb WD Caviar Blck Windows 7 Ultimate x64 Dell 24" LED Logitech MX3200
PowerCaseMouse
Thermaltake Toughpower XT 875w NZXT Phantom (White) Generic Dell optical
  hide details
Reply
post #7 of 15
The motherboard itself is fine, but the VRM phases (the various whatnot surrounding your socket) are not up to the task of high OCs; there have been reports of... bad things happening to mobos like these.
post #8 of 15
The good reviews may be for people running this board with <95W CPUs. This board and variants are capable of failing on 125W processors at stock. Since you don't have the stock cooler either and there is absolutely no cooling to the VRMs/MOSFETs (which instantly triples the danger), I would try and take off a good chunk of voltage and perhaps even clock speed along with it.
post #9 of 15
Thread Starter
wow i just cant believe that this is that serious. This sucks i just drained 100 bucks into something that will not perform as advertised. I have twice the recommended case cooling going on that should count for something right?

CPUMotherboardGraphicsRAM
Phenom II 1090t @ 3.86ghz ASUS M4A87TD EVO Firepro V7800 16gb G.Skill Ripjaws
Hard DriveOSMonitorKeyboard
1tb WD Caviar Blck Windows 7 Ultimate x64 Dell 24" LED Logitech MX3200
PowerCaseMouse
Thermaltake Toughpower XT 875w NZXT Phantom (White) Generic Dell optical
  hide details
Reply

CPUMotherboardGraphicsRAM
Phenom II 1090t @ 3.86ghz ASUS M4A87TD EVO Firepro V7800 16gb G.Skill Ripjaws
Hard DriveOSMonitorKeyboard
1tb WD Caviar Blck Windows 7 Ultimate x64 Dell 24" LED Logitech MX3200
PowerCaseMouse
Thermaltake Toughpower XT 875w NZXT Phantom (White) Generic Dell optical
  hide details
Reply
post #10 of 15
Spent $100!? Newegg I presume? Yikes, that sucks. If you're within the 15 day non-defective return guarantee, capitalize it. Get this board which is much better for the same price
