These are rating from 01/01/2013 up to the last post. Please dont mind the bad spelling and typo's.
Thanks:thumb:Okle (Click to show)
Nice job on the front and back. The cables look tight behind the PSU, GPU cable isn't lagging and the 24pin cable is curved just right. All around nice job. 9.2/10SpecializedPro (Click to show)
GPU stacks! Time to get those cards wet! The cable management in this case is exceptionally good. Cables on the gpu run clean and some what uniformed with each other. Nice rig and clean cables. 9.5/10Frazz (Click to show)
Originally Posted by Frazz
Finally got cable sleeves:
Nice! Lets see the rest of that case. iPrevailed (Click to show)
Originally Posted by iPrevailed
Clean up the bottom cables on the mobo and behind the GPU and your set. Nice little rig too! 8.5/10Midgethulk (Click to show)
Originally Posted by Midgethulk
I'll just throw it in here.
It's a little dark, so I can't rate. But, from what I can see, it doesn't look bad.crazyg0od33 (Click to show)
Sleeved cables are a plus, but they still need to be executed correctly for a clean look. The area behind/under the ssd, behind the pump and the top behind the 5.25" bays can use a little cleaning. If you can route your cables that are behind/under the ssd behind the 5.25 bay, that will clean up that area. Even if you can't hide the Pump Cables, you can route it to where it looks clean. If you can get the other sleeved cables as clean looking as the 24pin cable, it would be that much better. Other than that, you have a really nice build. 9/10.JAM3S121 (Click to show)
Originally Posted by JAM3S121
How does my pc look? I am not great at taking photos, the lights are actually purple ( I messed with my camera's white balance so it showed propery. I am working on sleeved cables soon and getting new lightning in the case. I know the bottom PCI-E cables could be snugger and tighter but I wanted them to have that loop look. Thanks
You can't see it but in the top left cutout there is the cpu power and case fan power plug.
I'm not gonna lie, I like the purple lighting. From what I can see, the cables look really good. Everything looks tight and curved just enough. But the pics is a little dark, can't see what rest of the cables look like. 8.5/10Frazz (Click to show)
Originally Posted by Frazz
Hardest thing to manage is the CCFL and inverter.
There's the rest of the rig. Nice extensions, I would tighten up the GPU cables and shorted the curve of the PSU cables. Zip ties are your friend. Nice rig though. 8.3/10CyGnus (Click to show)
Originally Posted by [CyGnus]
I have a Cooler Master K350 very bad cable management case no space at all to hide them, tell me what you think and what i can do for better management thanks
PS: i have zero space behind the MB tray
not bad, I dont know how it can look any better? Proper use of zip ties and the pony tail on the PSU is pretty clean. 7.5/10GoLDii3 (Click to show)
Originally Posted by GoLDii3
Just got a Phantom 410
I would tighten up the gpu and 24 pin cable with some zip ties and shorten the length of cables. Looks pretty clean besides what I mention. 8/10shadow water (Click to show)
Now that's some nice cable management front and back. Also, the color scheme flows with the entire build. I know that took a while to do. Nice job all around 9.6/10.xlastshotx (Click to show)
Originally Posted by xlastshotx
Some pretty nice cables no?
Yes they are. PoisonousRakija (Click to show)
Originally Posted by PoisonousRakija
Did some more tucking in and painted the CPU cooler from green to black/white. How do we like it?
Going to add some more fans and lighting soon too.
Clean and simple. The cables look tight and well manage from the bottom up. Can't complain with the simplicity of this build. 9/10.OverClocker55 (Click to show)
Tighten up those gpu cables. Other than that, nice cable management. I like how you tucked the cables under the mobo. Really clean looking. 9.5/10Rust1d (Click to show)
Originally Posted by Rust1d?
Use some zip ties on the cables under the mobo and tighten up the 24 pin cable. 7.5/10Tigerboy (Click to show)
Originally Posted by Tigerboy
if you have any tips by all means please leave em here or msg me. this is my first real attempt but i have a good case for it
gonna get black sata cables cuz that red one sticks out too much
^^ I was just going to say that. The red cable under the CPU cooler can be tucked away as well. Can probably use some zip ties to clean up those cables under the mobo. Not bad at all though. 8/10Born For TDM (Click to show)
Now that looks clean. The only eye sore is the miss matching cable on the bottom card. Besides that, nice job on the cable management. 9/10Rixon (Click to show)
Originally Posted by Rixon
Re did my cable management since I got my Segate barracuda 1Tb drive in earlier this holiday season, I'm glad I was able to find the time to wrench that annoying EPS cable behind the motherboard tray, desipite the 650D being awesome at cable management.
Although when I tucked everything together those pesky SATA and 4-pin molex cables were tied up and hidden from the HDD bay access hole, I really need the money to put the hardware that this case deserves in it.
As for Born For TDM's post, that is almost completely immaculate man, no doubt it is a 9.8 or 9.9 of 10. The only thing I would like to see is maybe hiding the second GPU's power cables behind the first, or even weave them together to get rid of that loop but keep the contrasting black and blue colours.
Use a zip tie to clean up the gpu cable. If you can hide the cables in the back of the mobo so it's not visible through the grommet holes. 8.5/10ekg84 (Click to show)
Nice to see your still pumping out some clean looking rigs. Everything about this rig is clean, back and front. Nice job all around. 9.8/10 Bazinga69 (Click to show)
Not bad, I see proper use of zip ties on the cpu and the PSU area looks very tidy. I dont think there's much you can do to make it look better? I would probably work on the cables behind the ODD, but other than that, it looks good. 8/10HPE1000 (Click to show)
Originally Posted by HPE1000
I will be like anyone else on here and say 8.5 because the cables aren't sleeved
This is far from being done, I am setting the computer up right now (windows, driver, programs, transfering data etc..) and that was a quick job, heatsink and GPU will probably be ordered tonight. It's my brother computer I just built him today
Electrical tape on the 24pin cable FTW. I've done that a couple of time on my earlier builds. This is late, but I'm sure you're brother appropriates you building his computer instead of going to BestBuy. As far as the cables, not bad. I'd probably put the same amount of effort into a family build too. The cables I would clean up would be around the bottom grommet hole, I would route the cables over/under so their not as visible. If you wanted, you can run the 8pin cable behind the mobo so it's not as noticeable too and straiten up the cables under the mobo. Not bad though, 7.5/10.THC Butterz (Click to show)
Originally Posted by THC Butterz
How bout my rigs,
I also Have a 932 but Ill Be Re doing in in the next day or 2 when my new ssd comes in
1st Computer: other than the cables behind/under the 3.5" bay, the cables look pretty neat and tidy. Normally those cables wouldn't be visible, but the angle of the picture and the flash make bring them out of hiding. 8.8/10 2nd computer: This one is clean as well. The only two cables that stick out to me is the exhaust fan cable and the 8pin, wouldn't be bothered to try and hide them unless you had the time. 8.8/10 3rd computer: Nice 360 in the front! The gpu cables look really clean in the rig. Tucked away and uniform, nice job. I would rate this a 8.9/10 because I can see the cluster of cables behind the rad. All around clean looking builds, what do you use them for?Zeek (Click to show)
Originally Posted by Zeek
Your cable management looks great in all the rigs
Can't really do "good" cable management in this case, but it's better than nothing
SSD is on the other side behind the motherboard tray so I didn't have a huge mess on the bottom, even tho I still do, lol.
I see you ran some cables behind the mobo, nice. Doesn't look like there a lot of room for cable management? Looks good from what I see, 8.8/10.Disturbed117 (Click to show)
Originally Posted by Disturbed117
Here is mine. I need to do some more work on it though.
Picture (Click to show)
All I see is the 24pin cable and one of the cables behind the PSU. I can't see much because of the dark picture. But I'll rate it a 8/10 because looking closely at it, it looks like you've routed the cables pretty well.raidmaxGuy (Click to show)
Originally Posted by raidmaxGuy
Ok let's try this again. Maybe my post won't be overlooked
Mine... Nothing to brag about but it is fairly clean, but you really dont want to see behind the mobo tray , it's scary. Although if someone wants to help me brainstorm on how I can route everything back there I can provide a picture...
I wish my Sata power connectors didnt have so much extra length between plugs though, got that weird looping stuff going on...
I had the hardest time finding 6" sata cables in store so I had to settle for half meter cables.
Advice? Ideas? Both are appreciated. :3
If you have/get longer sata cables, you can run the sata cables through the grommet hole right next to the GPU and use a zip-tie's to keep it looking straight and tight. Since you don't, I would straiten those sata cables and use the zip-tie anchors to tie them down, I see two of them that you can use. Would probably look better than having them curved like you do now. Clean up the extensions on the 24pin and the GPU cable. Also try to hide the HDD cables. Only if you can. It's not worth it if it's gonna be a pain. Other than that, you have a good looking rig. 8.5/10Bmxant (Click to show)
Originally Posted by Bmxant
The back panel was hit by a tornado, you're not allowed to see it
Like the blue LED's. Need a better pic so I can rate. famous1994 (Click to show)
Originally Posted by famous1994
Just switched to a Rosewill Blackhawk that I won from the Community Awards, thoughts?
Any free case is a win, especially if it's a brand new one.
The pic is a little dark around the PSU area and behind the bay's. But I can see enough to make a rating. The cables behind the PSU look clean and uniform. The GPU cables look pretty good, from what I can see. Proper use of grommet holes but the red sata cable sticks out more than anything else. I would try to straighten it out. 8.5/10Layd Dly (Click to show)
Originally Posted by Layd Dly
Almost where i want it. I think i may need to get into some custom sleeving though.
Pretty clean looking to me. The PSU, 24 pin, and the sata cables look uniformed. The only cables that need work are the front panel cables. 8.8/10.ericlee30 (Click to show)
From the bottom to the top, this is clean cable management. I like how you ran the power/USB/Audio cables behind and under the mobo. The GPU cables, did you run that through the shroud? Because it looks like you did, which is SMART. LoL, a good idea and looks super clean. The sata cables are lined up and colors are matching. I see a black cable running behind the odd/hdd bays, but it not that noticeable since it's tucked away nicely. Nice job! 9.5/10.bdenpaka (Click to show)
Originally Posted by bdenpaka
ok, you get a 10/10 since the only cables I can see are extremely clean looking. All the cables are combed to perfection and layered like a three layered cake. Nice job! l3eans (Click to show)
Originally Posted by l3eans
Gotta fix that 24 pin pretty badly.
The rig as a whole looks nice. I can see the cables in the HDD bay, one cable through the grommets and the sleeved/extensions needs a little TLC. Normally wouldn't see those cables in the bays, but your flash makes them noticeable. So unless you have the time to mess with it, it's not a big issues. 9/10. Cruz (Click to show)
Originally Posted by Cruz
It looks good to me. What looks like a floating HDD sticks out and the shoe box. =D But the cables in the rig look pretty clean. I would bring the 24 pin a grommet higher so it has a nice curve to it. 8.5/10.Davcos (Click to show)
Originally Posted by Davcos
Rate my cables
(no front audio plugged in)
yeah, this is clean all around. All the cables are uniformed and tight. And no cables visible through the bottom grommet hole or behind the bays. Well done! 9/10.overamdclock (Click to show)
Whoa, not gonna lie, it needs some work. Doesn't look like you have much room for cable management, so zip-ties will be your best friend. Just take some time and you'll get it looking right. But for now, 3/10.Master__Shake (Click to show)
Originally Posted by Master__Shake
Rate my living room PC's cables
The GPU cables could look a neater and the cables under the mobo as well. Nice placement of the res, hides the other cables.
8/10.WZ3r0 (Click to show)
Looks good all around. You should have ran the power/led/reset cables behind the mobo to finish off that clean look. GPU and PSU cables look tidy and clean. 9/10Renairy (Click to show)
Originally Posted by Renairy
Just installed my Gainward 680's and H80i
Need a better pic, It's too dark.wanako (Click to show)
Cool looking 2P rig. Proper use of Grommets, the sata cable stack is layered nicely, and all around looks pretty good. I would try to clean up the cables under the mobo, but not a big deal. 9/10Decade (Click to show)
Originally Posted by Decade
Can't see the CCFL's cable when the side panel is on.
Window needs cleaning + faintly see glow from UV CCFL.
Switch 810, sleeved cable extensions.
Man that S810 makes that sabertoom mobo look like a mATX. You've done everything right in this case as far as cable management goes. Used grommet holes, sleeved extensions and kept the bottom wires clean. The only issues I have with this is the cable extensions, nice you have them, but would look a lot cleaner if you can possibly make them look uniformed. Nice build though. 9/10.Swag (Click to show)
The front back look good. I would tighten up those extensions for that extra clean look. 9.3/10.Frodenstein (Click to show)
Originally Posted by Frodenstein
Hello ! My second try
I managed my cables for four hours.. Is is an improvement ? I got a 6.8/10 before.
BEFORE PICTURE :
AFTER PICTURE ( w/ flash and w/o flash) added some cathodes
oh and i found this guide :http://www.instructables.com/id/Guide-To-Computer-Cable-Management/step7/Covering-the-Holes/
this person is genius ! he used tape as a make shift cable grommet since the HAF 912 doesn't have rubber grommets
made things much cleaner
Like that you posted the before and after pictures. Really shows the effort and work that's went into it. I would tighten up the ODD cables, hide the 4-8pin power cable, and clean up the cables under the HDD. 8.5/10Konkistadori (Click to show)
The 24 pin cable looks really nice. The cables in the very far back right..tuck them away. 9/10 SeanOMatic (Click to show)
Originally Posted by SeanOMatic
Just ordered the 300R extra drive bay kit so I can add two SSD's in the upper bay. Waiting on a GTX 660 to show up. The sound card is a Xonar DSX. PC Power Silencer 910 PSU, which was a mighty ***** to get the cables neatly routed behind the tray and close the 300R up, but I got it done. Got the grommets from an 800.
The pics a little dark. Don't know if you posted another pic, but if you did, I'll rate it when I see it. baconbitz44 (Click to show)
Originally Posted by baconbitz44
You can see that I just kinda threw my two ssds in the bottom haha I really need a modular power supply... The tx750 is really hard to work with I just shoved them in my lower drive bays
Pop that side panel off, would like to see what's going on in there. You can probably use some Velcro or double sided tape to mount that SSD. trust-no-1 (Click to show)
Originally Posted by trust-no-1
/\ Supposed to be rotated 90 degrees.
/\ Organized chaos, I like it
Wadda we reckon guys?
Sleeved cables, nice. Dark Picture, not so nice. jas2377 (Click to show)
Originally Posted by jas2377
Case is the IN WIN GRone. Haven't seen too many of these cases posted, but it definitely gives a ton of room for cable management.
This deserves a 9.5/10. Clean looking all around, even though I see some electrical tape. dragonfly789 (Click to show)
Originally Posted by dragonfly789
New Case (HAF X) first attempt at decent cable management
I would tidy up those cables on the bottom, but from what I can see....it looks like a nice job on the cable management. 9/10ploppercon (Click to show)
Originally Posted by ploppercon
I'm **** at cable management
eh, I wouldn't get so discourage at it. It does take time and patience to get it done right.....oh, and some zip-ties. First off, I would route all the PSU cables through the grommet hole, then take it from there. socketus (Click to show)
Originally Posted by socketus
Nobody bites here, and if they do, they get warned. So go ahead and post it.
I'll start off with my Silverstone TJ-04
Look at that wave of sleeved cables. It actually looks cool, the way it's laid out. Why didn't you run the cables behind the mobo tray? Looks good, but def. could look better. 8.5/10.TheRacker (Click to show)
Originally Posted by TheRacker
How'd I do?
8.5/10 Nice attempt and doesn't seem like you can do anything major to improve it. Maybe clean up the rats nest on the PSU? It's clean looking though considering the old PSU. SmokinWaffle (Click to show)
Originally Posted by SmokinWaffle
9.5/10, could make the front panel connecters a little nicer looking, but very very neat.
Built my work PC today, didn't spend too long on the cables but I'm pretty happy with it. The fan controller under the drive bay is relocated from the rear vertical PCI slot as it was a mess with it there, this way I can keep all of the fan cables in one place and the molex doesn't look unsightly.
Everything in this case was done right. Proper use of grommets, tight cables from the bottom up, and even the cable on the CPU cooler is tightly tucked away. Other than the fan controller cables, a nice job all around. 9/10TempestxPR (Click to show)
haha, cute pug. My brother has two.
Your cables are clean, but can use some work. I would tighten up the PSU cables on the bottom and rought them through the grommet closes to the PSU. That way it'll free up the bottom of the case and show case the bottom green panel. I would tighten up the gpu cables and close that gap. Route the 24pin cable through the grommet closest to the 24pin connecter, it'll look cleaner with a nice curve. Not necessary but if you can probably route the cables better instead of shoving them inside the HDD cage. Not bad though, what kind of green did you use? 8.7/10CasperGS (Click to show)
Originally Posted by CasperGS
I would rout the cable leaning on the PSU through the grommet hole. The cables behind the ODD can be cleaned up and the ones under the HDD can be hidden a little better. Not bad though. 7.8/10Stige (Click to show)
Originally Posted by Stige
/10CroSsFiRe2009 (Click to show)
Originally Posted by CroSsFiRe2009
Antec 300 and oldish hardware. Rate?
Nice job considering the difficulty of hiding cables in that Antec. 9/10.justarealguy (Click to show)
Originally Posted by justarealguy
She needs some more cleanup and some sleeving but man am I happy with this case.
Pretty tidy in there, minus the little red and yellow cables on the bottom that are visible. Route the cables around the bottom square hole so the cables aren't so visible. Use the grommet closest to the bottom mobo to hide the cable that goes to the Raid controller (not sure what it is)? Other than that, nice job. You use grommets closes the the connection points for a clean look. 8.7/10Fuggins (Click to show)
Originally Posted by Fuggins
custom laser etched acrylic window that I had done at my work too
single braids just got in today and i was super excited. iphone took a pretty crappy picture though and the orange/blue color scheme looks way better in person. all in a NZXT 810 switch.
I'll rate what I can see since the side panel is on. The PSU cables behind the PSU look tight and clean. The GPU extensions could use a zip tie or two and maybe layered better for a cleaner look. The 24pin cable looks ok too. Could layer it for a cleaner look. Again, a clean looking rig and really not necessary unless you have the time or want to change the look. 8/10naved777 (Click to show)
Nice looking pics. As far as the sleeved cables, tighten, layer and use some zip-ties on the GPU cables for a cleaner look. Can't really see the rest of the rig so it's a 7/10. Stevesack (Click to show)
Originally Posted by "
Sleeved cable a plus, still needs some effort for a clean look. I would clean up the bottom cables that plug into the mobo, tighten up the cable extensions on the GPU and the CPU and route the sata cables a little better. Cool looking rig though, very bright green.
8/10BradleyW (Click to show)
Originally Posted by BradleyW
I like the noctua fan posted up behind the cards.
What's the diff. in temps with it on? As far as cable goes, I would try to clean up the gpu cables, maybe run them through the grommets? I see some cables behind the front fan that can be tucked away too. 8.8/10WizrdSleevz (Click to show)
Cool SFF rig. The only thing that sticks out to me is the white cable coming from the fans. Maybe if you you routed them so their not in plain view, it would look better. Really clean build though. 9.5/10.jlhawn (Click to show)
Originally Posted by jlhawn
heres my cables. I wish I had sleeved but i'm not sure if they would look bigger and take up more space.
corsair has a set for my AX1200. any advice you all can give will be taken into consideration.
All the cables coming out of the grommets, which is a plus. I would just try to straighten out the GPU cables and layer them for a better look. Well done. 9/10 famous1994 (Click to show)
Originally Posted by famous1994
Rebuilt my brother's PC today and did the cables. It was kinda hard being that his case is a Thermaltake Soprano RS. I think it came out pretty good though.
Looking good! Nice job keeping the psu cables ziptied. It's a pain in some of cases when the PSU is on the top and there is no room in the back of the mobo tray to hid the cables. 8.5/10.theknappkin (Click to show)
Originally Posted by theknappkin
Finally added some red sleeved cables to my rig so i though i should post here
GPU cables zip-tied, check! Sleeved cables Check! Clean looking rig, check! Angled pic, awesom, but I'd like to see the rest of the rig for ratings. 8.5/10.theMetal (Click to show)
Nice job. All I see is are the sleeved cables and the blue sata cable, which look clean. Pretty bright too since it takes away from the rest of the rig. The only cable that stuck out, was the top fan cable. It was hard to spot, only noticed it when I blew up the pic. 9/10 Binary Ecyrb (Click to show)
Now this is a proper way of using zip-ties. I would clean up the sata and the cables around it and shorten the 24pin curve. Clean looking rig bud. 9/10.vio2700k (Click to show)
Cables are well hidden in the 800D. Not much you can change in there other than titening some of the cables. 9/10Yeti Poacher (Click to show)
Originally Posted by Yeti Poacher
Alright let me have it!
9.5/10. Very clean. The gpu/cpu cables are layered and tight looking as well as the other cables. Proper use of grommet holes. Super clean job you did there. SteevyT (Click to show)
Originally Posted by SteevyT
Here's mine, it isn't the greatest, but with the limited length of some of the cables I don't think I did terribly.
The cables behind hdd could use some cleaning up. The cable on the cpu fan and the rear fan can be tidied up. It would probably look better if you used the grommet hole to route your 24pin cable. There's plenty of room in the back of that source to clean up those cables.
7.8/10driftingforlife (Click to show)
Originally Posted by driftingforlife
Just re-did my work PC.
I dont know if I rated this previosly but here it goes. All together, the cables are in a straight line and from the PSU up, the cables look neat. I can see you hide you front panel cables behind the PSU ponty tail, Smart. I can still see the bow of rainbow cables in the front behind the bottom frontDylanren99 (Click to show)
Originally Posted by Dylanren99
Not too bad for a first build dont you think?
There are some area's that could use some improving. The front panel cables under the mobo could be tucked away a little better. The cables on the top and the 120mm fan cable on the rear sticks out to me. Other than that, not bad for you're first build. 8/10.Crazycarl (Click to show)
Originally Posted by Crazycarl
well i guess heres mine suppose could use some work
Pretty tidy in there. I would zip-tie those front panel cables and route them a little better. Tuck up the front panel cables in the back so it's not visible once you close the back panel. I dont think you can really do much for the hdd's cables?? 8/10.roudabout6 (Click to show)
Originally Posted by roudabout6
Just finished routing my cables
Still need a couple things though. Been upgrading this computer since I got it 2 years ago
P.S My tubing is blue I took this with my phone
That's a cool AIO tube mod. The sleeved cables look really good too. The only thing I would do is layer those cables a little better. 9/10.Calpern (Click to show)
Not bad. I can tell some work went into this one. You even tried to tuck most of the cables behind the 5.25"/3.25" bays. Improvements would be.....not really sure? lol All the cables have a good curve/bend to them and even though some of the cables are noticble, I dont see any other way to route them? I would proabbly keep the way you have it and just tuck the cables behind the bay's a little better. 8.8/10.xplode-bg (Click to show)
Originally Posted by xplode-bg
Here is mine
Thermaltake Chaser MK-1 (which many hate and I love)
Back looks like a mess but as long as back panel closes normally it's OK.
Front USB3 cable in the corner, and PCI-E power cables around the graphics card
I lost my second PCI-E power cable (modular crap) so i ordered parts to rebuild one, until then i will use molex to PCI-E converter as seen on the pic, its looks ugly but for now it will be like this.
Just below the motherboard there are the front audio cable and Front USB2 cable together, Next to 4 SATA3 cables which i grouped 2 by 2 to take less spaceand not interfere with graqphics card fan
Proper use of grommets, pretty clean routing of the cables. I would try to hid the molex cable as it's the only cables that catch my eye. Other than that, not bad. 8/10 CS14 (Click to show)
Originally Posted by CS14
Decided to spend most of the day working on my cable management since the weather is bad. My 212+ came in the middle of working on it
Ignore the old graphics card in both the photos, temporary until my RMA'd 7770 comes Monday. Also ignore the iPhone quality photos
I think I did pretty damn well considering this is only my 2nd time trying to manage cables and this case offers no options to help with cable management on top of the fact the PSU isn't modular either.
Let me know if there are things that can be improved and suggestions for improving.
I would try to clean up the cables under the mobo, only if you can. Try to tuck them behind the mobo tray of have them coming out of the bottom grommet hole. A pretty good improvement from you're previous attempt. 8/10.ViperSB1 (Click to show)
Originally Posted by ViperSB1
That's a nice looking rig. The only cables I notice are the LED's cables on the top for the cpu. The gpu cables look good and the 24pin looks extremely good. Nice job all around. 9.5/10.n3gr0 (Click to show)
Originally Posted by n3gr0
my sleeved cables!
oh man, so compacted. Nicely done! I would layer the sleeved cables a little better.
9.5/10.Xyro TR1 (Click to show)
Originally Posted by Xyro TR1
It sort of sucks building in a case with no cable management...
- Fractal Design Core 1000
- Intel i5-3470
- ASUS P8H77-M/CSM
- 8GB G.Skill DDR3-1600
- Corsair CX 430W
- 128GB Samsung 840 (or) 120GB SanDisk Extreme
- AIO card reader
- DVD+RW drive
What you DON'T see...
9.3/10. Love Core 1K case! Looks like that's as good as it's going to get in that case. Nice job!Evil Genius Jr (Click to show)
It's pretty clean in there. All the front panel cables look tidy and and the rest of the cables look neat too. Pics a little dark to really see the details, but job well done. 8.5/10.PinzaC55 (Click to show)
Originally Posted by PinzaC55
Well I got no comments on the backside of my rig earlier so here is the business end. I've just done my nth bit of tidying up and ditched the internal DVD drive, saving me two cables
Also I just realised how horrible the label on top of the PSU looks - it has to go!
Don't know if I've already rated the backside?? But the front is looking good. I see a slew of cables off to the right that can use a zip-tie or two. Try routing the GPU cables under the tube, would look a lot better imo. 9/10.SmokinWaffle (Click to show)
Originally Posted by SmokinWaffle
Love it. Why did you go with that case over the PS07B out of interest? Surely the two x 120MM front instead of 1 x 180 is much preferable for watercooling. Looks sick though!
Here is my secondary download PC that is left on 24/7 to download/as a fileserver. Celeron D in a junker ATX case that I got for £10 with faulty S478 internals. Ripped them out, kept the PSU and replaced the inside. For a case with absoloutley zero cable management, I don't think I did too bladly. Not to mention I had to use a 20 > 24 Pin, 4 > 8 Pin and 2 X Molex > SATA adapters..Another picture
The fans are all ghetto zip tied on, only ones I had spare and they are silent, nice to have a little airflow.
I like that first pic, really makes the cables look clean. I would tighten up the cables on the top and clean up the cables on the botttom with some zip-ties. Not bad though!
8/10Bazinga69 (Click to show)
Not bad, no need for a modular PSU if it's looking that good. Unless you just want it, like most of us here on OCN.
As far as your cables, you did a nice job hiding most of the cables and keeping them clean with zip-ties. Nothing major I would change as the cables look pretty neat...unless you go sleeved. 8.5/10.Nemesis158 (Click to show)
oh man, looking good. A proper use of cable extensions and I see you're using an abundance amount of zip-ties. Like that the gpu extensions are comb to perfection. All around nice work. 9.3/10kcuestag (Click to show)
Originally Posted by kcuestag
Bought an XSPC Dual Bay Acrylic Reservoir for my D5 pump to make it all look much cleaner:
Hope you like it.
PS: Ignore the cables behind the bottom rad, can't hide those since that's where my SSD is sitting at.
Not bad bud. The only two things I would clean up is the GPU cables and the behind the rad where your SSD sits. I know you mentioned you can't, But I know you can.
Similar SSD Mount (Click to show)
9/10 Xyro TR1 (Click to show)
Originally Posted by Xyro TR1
Yet another client build.
> Fractal Design Define Mini
> ASUS P8Z77-M PRO
> Intel i7-3770K
> 16GB G.Skill DDR3-1600 1.35v
> ASUS HD7770 2GB
> Corsair HX650
> 2x Samsung 840 Pro 512GB in RAID1
From the bottom up all the cables are uniformed, tightly tucked away, straight and routed neatly through the grommets. A really good job all around. 9.8/10 zer0entropy (Click to show)
Originally Posted by zer0entropy
Sorry for the darkness of the pic.
BTW Swag, that thing is NICE 10/10
The darkness! I dont know, the cables coming for the SSD are really noticable and the SSD is slightly crooked. Work on hiding those cables and straitening out the ssd and it'll look better. I can't really see what else is going in there so I'll just rate it for what I can see. 7/10Kornivsky (Click to show)
oh my Glob! I would just start all over. Buy some zip-ties and go to town. Only if you have the patience for it. 2/10Pebruska (Click to show)
Originally Posted by Pebruska
So here's my cable management, and just to be clear this was just a quick build and i didn't bother to spend much time with the cables.
Tell me, is it acceptable? Maybe i should have a crack at them and see if i could do better.
Acceptable, very much so. If you didn't take time to really put work into it, I'd like to see what it would look like if you did. Looks good in the front and the back. Not much I can think of to really improve the cables besides sleeved cables. Nicely done! 9/10. Gavush (Click to show)
Originally Posted by Gavush
I was going to buy parachord and do black sleeves but decided not to spend the time or money on the rocketfish psu and I already had a spool of wire harness tape for motor vehicles so I tidied things up that way instead.
That actually looks good. I would straighten the cables up to give it that extra clean look. Other than that, it looks good. 9/10tig33r (Click to show)
Originally Posted by tig33r
That's my wm
hmmm, what stuck out at me the most was the cable on the CPU fan cooler. I would try to tuck that under the cooler/fan. Looking closely at you're rig, you did a really good job. The other thing I would do is clean up the GPU cables and maybe tighten up the front panel cables. 8.8/10.cookiesowns (Click to show)
Nice job bud. I would only tighten up the GPU cables. 9/10Chillie (Click to show)
Originally Posted by Chillie
What yall think?
Tighten up the front panel cables and make them run parallel for a cleaner look. Clean up the PSU cables on the bottom with some zip-ties. I would re-route the GPU cables under the GPU so it's not making contact with the fans. 8.7/10 Phil~ (Click to show)
Originally Posted by Phil~
The top cables on the right can probably be hidden a little better or use a zip-tie to tighten them up. Other than the missing GPU cables, It looks good. 5/10 because of the missing GPU cables. TSXmike (Click to show)
Originally Posted by TSXmike
(ack, dark picture)
still on the fence about sleeving my cables in paracord. part of me REALLY wants to do it, but the other half is still a little on the nervous side.
Sleeving you're cables would give it that extra clean look. I can't see much because the pic is dark. The only visable cables are the gpu cables and the 24pin. Maybe take a better pic so we can see what your working with. Terreos (Click to show)
Originally Posted by Terreos
I just dusted the inside of my rig and decided to fix the wires some. Here it is before.
And this is the cables as they are now.
Look at the improvement. Nice job all around. I would clean up the straggler cables on the bottom of the case and on the top right. Tighten up those front panel cables and your set. 8.8/10.estabya (Click to show)
Holy case! Sleeved cables a plus but clean them up a bit. Layer them a little better and try to tighten them up. Cool looking build bud. 9/10.pm1109 (Click to show)
Originally Posted by pm1109
Heres my rig guys
The GPU and the 24pin cables are the only ones I see. I'd try to layer them a little better for a cleaner look. 9.3/10. The water looks a little murky?cgg123321 (Click to show)
Originally Posted by cgg123321
Just cleaned my rig (only a few times a year, yay for fan filters!) so I decided to take a few photos.
Look at that picture quality!
Everything in this build looks outstanding. The cables are spot on! The Special Edition GPU complements the Noctua fans. Awesome work bud. A really clean looking build. 10/10Rangerjr1 (Click to show)
Originally Posted by Rangerjr1
Ahh i wish i had sleeved cables
. I had the c70 but i couldnt get it to look nice at all. so i bought a new case.
Also your name rustles me.
Straighten out those cables coming out of the top grommet and use some zip-ties. Clean up the cables coming from the Noctua fans and try to hid them. Other than that, looks pretty clean. 8.8/10.nleksan (Click to show)
Originally Posted by nleksan
Excuse the missing section of tubing, pic was taken with the loop in a state of dis-assembly
Argh, I forgot I pulled the 24pin back through the grommet to more easily work with the PITA connection between the EK and XSPC reservoirs :S
The back and the front are pretty neat looking. I would tighten up those GPU extensions. Other than the missing 24pin extension, you have a clean looking rig. 9/10.Rixon (Click to show)
Originally Posted by Rixon
Very nice, right now 9/10; once you get around to pulling the 24 back around its a 10 from me. Here is a build for a friend of mine I just finished, it's got
ASUS ROG Rampage IV Formula
MSI GEFORCE GTX 680 4GB Twin Frozr
G.Skill Trident X 32Gb 2400
Corsair H100i Watercooler
Corsair AX760 PSU
2x Samsung 840 PRO 256Gb
Seagate Barracuda 3TB 7200
Asus Xonar DGX sound card
Asus Blu-ray Read and writer
ASUS PA248Q monitor
The AIO cooler cables could use a zip-tie and maybe could be hidden a little better. The bottom cables coming off the card(?) would look better if they were a little discrete. Not a bad looking build. 8.8/10HyperMatrix (Click to show)
Originally Posted by HyperMatrix
Just have that one loose cable connected to the mobo on the left of the pic. That's with 5 SSD's and one HDD and Optical drive connected. So imagine the mess of Sata and Power cables behind the case.
BEAST! The yellow cables on the left and the pink/red sata cable are the only cables that stick out to me. The cables on the GPU look pretty good too. Beast of a build bud. 9/10fast_fate (Click to show)
Originally Posted by fast_fate
Curlicue project near completion.
No more cable work to be done ( I hope )
So please rate as you see fit.
Next project - will be harder with the cabling as 4 x 580's underwater go in the PCIe slots (not the 690's as in picture)
The cables are Layered like a Boss! Front and back looks superb! 10/10shadow water (Click to show)
Another clean build! Even the HDD cables are clean and tight! 10/10 Paradigm84 (Click to show)
Originally Posted by Paradigm84
Looking through all these tidy cases makes me feel sad, I need to get some extensions or sleeved cables.
I blame the HAF-X for having rainbow front panel connectors.
No need for extensions, I've seen plenty of super clean builds on here with out extensions/sleeved cables. But, it is a bonus. Tighten up those front panel cables and try to run them parallel to each other for a clean look. You can also rout them under the mobo for a cleaner look. 8.5/10.Zeek (Click to show)
Originally Posted by Zeek
Wow, 10/10 from me. Awesome job
My daily rig. Best I could do in a Antec 902
Crappy pictures ftw
Not bad for an antec. What's hanging on the top right? Looks out of place. The red cable on the top left, and the bottom cables can be tightened up. Nice work though. 8.8/10.jammo2k5 (Click to show)
Originally Posted by jammo2k5
got upgraded on my RMA of my Z1000W. Just redid my entire cabling to hide all the wires that aren't black.
Clean looking rig. The front panel cables are hidden very well. I'm assuming they are routed behind the mobo. I would try to straiten the 24 pin cable and try to make the GPU cables a little more uniform.Other than that, clean looking rig. 9.5/10Nedlamar (Click to show)
Originally Posted by Nedlamar
Well since I just finished my CMST mod, I thought I might as well join this thread too
It's not the best, I fully intend on creating my own cables within the next couple of months and have it true perfect.
The Mobo power cable was just too short to route, so it had to go straight up and over, I wasn't particularly please with this, but needs must.
I have mixed feelings about this one. If you're going for "showing off my cables," then you did a nice job. I honestly dont know how to rate this one? So I would rate it 6/10 for having a unique look.Scott1541 (Click to show)
Originally Posted by Scott1541
The result of today's work:
As the more observant of you may have noticed, those aren't grommets, they're just pieces of rubber that I cut down and fixed to the back of the holes to cover them
It nearly looks just as good as a grommet.
That's a really good idea, looks good too. I like how you have your gpu and usb3 cable paired with your 24pin. I would change the zip-tie to a black one, as the white one is really noticeable. The top fan cables can be tucked away and the front panel cables can look neater. 8.8/10.remixedMind (Click to show)
Originally Posted by remixedMind
Rocking a core 1k case, a really nice case for the price. Cable management can be tricky in this case. Using the HDD cage that mounts on the side will help hide most of those cables. I would take all the cables and route them through the hole on the bottom of the 5.25" then route them accordingly. Use some zip-ties too.
7.5/10.broadbandaddict (Click to show)
Originally Posted by broadbandaddict
Hey guys. Just got done reassembling my rig with a new mobo, CPU, HDDs and fan controller. This is the best I can do for the time being. I really need to sleeve this PSU. Pictures (Click to show)
I would route all those cables through the grommet hole under the mobo instead of around the fans. I would also tighten up the cables coming off the PSU. I know it's a little hard to hide those ODD/HDD cables, but it looks like it can be tucked away a little neater. Sleeved cables would def. give your build a clean and more uniform look. 8.5/10.Renairy (Click to show)
Look's pretty neat in there. How you liking the Titan? Can't really see anything I'd change besides tightening up the gpu cables. 8.8/10.chase11 (Click to show)
Originally Posted by chase11
Not as pretty as all of the others but it is something.....
The 24pin cables looks spot on. I would clean up the cluttered cables on the top left. Tighten up the cables coming out of the PSU and layer/tighten up the gpu cables. Looks good besides those things I pointed out. 8.8/10.logoris (Click to show)
Originally Posted by logoris
here is mine there is no video card because its a server but what do you think any and all tips welcome just finished it today
I would clean up the front panel cables, route them behind the mobo and through the PSU grommet hole. If you can rotate the cpu cooler so the cables are on the top, it would look cleaner. Get a non-90* sata cable or try to route the sata cable through the bottom grommet so it's not as noticeable. But for a server, since it looks ok as it sits. If you have the time, go for it. 7.5/10. KyleMart06 (Click to show)
Originally Posted by KyleMart06
Wow, a lot of posts here with pics. I think mine will be crowded out. Just Reorganized mine as well.
Like the before and after pics. The only thing I would change is tighning up the bottom front panel cables and re-routing the top cables on the top right. Other than that, looking better. 8.8/10mtrx (Click to show)
Originally Posted by mtrx
New case, temporary PSU/cables so only did a quick job on them.
Super clean! All the cables look really good. I would pony-tail the cables on the bottom, I think it would look better. 9.5/10.Dustin1 (Click to show)
I would tighten up the gpu cables and layer them a little better. Other than the missing extension, you did a nice job. 8.8/10Smanci (Click to show)
Originally Posted by Smanci
The amount of molex connectors behind the HDD cage is too damn high. I wonder how things will turn out with the PC-Q08 or Q25
Awesome cable management bud. From the bottom up, all the main cables look tight and straight. Nothing I would change in this build. Well done.
10/10SDBolts619 (Click to show)
Originally Posted by SDBolts619
I've got another thread going with some sleeving questions. I posted up in here a while back, but would like to get some feedback on these questions:
- Would it be worthwhile to redo the cables and sleeving to the HDD's/SSD's/Optical drives? I think the back of my motherboard tray looks decent, if not perfect and am not 'sold' on the reward vs. effort for redoing all those cables.
- My PCI-E cables are a little too short for my taste - I'd like them to stay behind the motherboard tray and come directly out to each card. So I'm figuring on making entirely new custom cables. However, if I fully single sleeve them, I'm thinking that they're going to be even bulkier than the current ones behind the tray. What about single sleeving them only where they're visible from the front, and sleeving them together behind the tray?
- Is this really clean enough and I'm totally going OCD trying to clean it up more?
Here's the current setup:
Would it be worth it, yes. But That's really up to you. I've seen many rig's on here that look good with out extensions/sleeved cables. In you're case, sleeved cables would really clean it up in there and give your build a better look. As it sits now, I would try to clean up your front panel cables. GPU cables would look better if they were straight. The back of the case looks really good though. Hope you work things out. 8.8/10.xxxaksxxx (Click to show)
Originally Posted by xxxaksxxx
There's a lot of nice rigs in here.
I'll attempt a shot at this, here is the cabling in my newly completed rig.
Sweet looking build. I would tighten up the cables on the bottom. Route the top GPU cable like the bottom GPU, it'll give it a more uniform look. Really clean build. 9.5/10.SpykeZ (Click to show)
Originally Posted by SpykeZ
Just finished my water loop and will be sleeving next week hopefully and getting rid of those ugly red sata cables. This is it how it stands. From my Build log
GiJoe! At least that what it looks like. Since you're getting rid of the red sata cables, the only thing I would clean up is the GPU cables. I'm liking the cooper theme. 9/10.Dav3ric (Click to show)
Originally Posted by Dav3ric
How's it look?
I do see a couple of stray fan cables that need to be addressed...*grabs zip ties*
Easy to miss that though since this is how it looks with the panel on.
Minus the stray fan cables and the GPU cables, you did a good job on cable management. I would route the GPU cables through one of the bottom grommet holes, would look a lot cleaner imo. 9/10.Kungfood (Click to show)
Originally Posted by Kungfood
Fire away, just finished it!
Nice cables, really goes well with your build. I would tighten up those cables on the bottom. Maybe pony-tail them for a cleaner look. The front panel cables could be tightened up as well. Nice job 9.3/10.Sgtbash (Click to show)
Originally Posted by Sgtbash
I got my first DSLR today
Go easy on my photos, most are done in auto mode!
Excuse the dust!
The bottom of the case looks clean, sata cables look stacked and properly routed, GPU and 24pin cable look nice and tight. Can't really see the HDD area, but from what I can see, you did a good job on the cables. 8.810.azrael36 (Click to show)
Originally Posted by azrael36
Just tore the PC down today and rerouted all the cables as well as I can with this case
Any thoughts or other tips more than welcome!
An improvement on the second time around, but still looks pretty cramped in there. The 8pin can be routed behind the mobo, just doing that alone will improve the look in your case. The sata cables would look better in black as they are really noticble and bring a lot of attention to the clutter behind the HDD's. If you can tighten up the cables in that area and route them a little better, I think it'll clean it up nicely. 7/10.shadow water (Click to show)
You're friend is lucky that you took time to manage his cables. Really clean from the psu up, and even the sata cables look clean zip-tied. Aside from the multiple colored cables, you did a fine job. 9/10.unequalteck (Click to show)
Originally Posted by unequalteck
The only cables I see are the 24pin and the gpu. I guess I can rate it since those are the only two visible cables to me. Both are layered nicely and routed pretty neat. 8.8/10.benfica101 (Click to show)
Originally Posted by benfica101
Here is my rig
Notice the GPU sag more than anything in your rig. Stick a black chopstick under it. I've seen someone do it on here before. As far as the cables, they look really clean. Layered and routed really nicely. I can see one cable peaking out of the bottom through the one of the holes.....which can be easily tucked away. 9/10.Unknownm (Click to show)
Whoa, none of those cables fit behind the mobo tray? If not, you can try to tuck them away in HDD cage. It will restrict some airflow from the front intake fan, but at least your components can breath a little better. For now, it's a 5/10, only because i've seen worse. Give it another try and post with results. Gman200108 (Click to show)
Originally Posted by Gman200108
Just rebuilt my whole rig yesterday, spent some time on cable management. How's it look?
It looks pretty good. The bottom Sata/PSU/Front Panel/HDD cables/ look a little cluttered. But with some zip-ties and hidding them, would look a lot better. Other than that, you did a good job. 8/10.Alastair (Click to show)
Originally Posted by Alastair
So what do you think of my cabling in my machine!
Not bad, looks clean in there. Add a zip-tie to the top fan cables and maybe route the GPU cables a little better. 9/10ampy60 (Click to show)
The only thing I do notice is the front panel cables other than that, every thing looks really clean. Nicely done. 9.5/10.wthenshaw (Click to show)
Those are some head turning pictures.
Nice work bud. Can't find anything I would change. 9.5/10Moomaster (Click to show)
If you have 22mm of space or more behind the mobo tray, that cold cathode Inverter can fit in the back. Replace the pink sata with a black one and tighten up the front panel cables. 8/10.skyn3t (Click to show)
Originally Posted by skyn3t
By the looks of how you have your cables sleeved and routed, It's look really good. Even thought you didn't post an overall pic of the rig, I think the cables speak for them selves. Nice work bud. 9/10.Eudisld15 (Click to show)
Originally Posted by Eudisld15
Xclio Touch 787 has it's limitation, but I keep pushing it further and further. Cable management wise.
Will be modding that 7950 sapphire in a week!
Sleeving will come in two weeks!
Kinda put off by the work involve with individually sleeving each wire
A bit dusty...
Route the front panel cables through the bottom psu grommet. The sata cables could use some work and the cables behind the GPU as well. 8/10.Jaren1 (Click to show)
Originally Posted by Jaren1
Alright ill post. Just built this about two and a half weeks ago
Re-route the GPU cables through the back and Grommet hole and the 8 Pin behind the mobo tray. If you can't route it behind to mobo tray, try routing it behind and through the CPU cut-out and over the mobo. Most of the time it'll fit. If all else fails, buy extensions. Other than that, tighten up the front panel cables. 8.3/10KSIMP88 (Click to show)
Originally Posted by KSIMP88
Clean up the AIO cables on the top near the block/pump. I would change the orientation of the rad on the bottom to see if that helps clean the clutter in that area. I would use the 5.25" bay to hide some of those cables if you have no room behind the mobo tray. It doesn't look bad, but with some time and paitence, you can make it look really clean.
6.5/10.MrTOOSHORT (Click to show)
Originally Posted by MrTOOSHORT
So I installed my old GTX 480 coming from my GTX 690 and I tidied up the cables a little bit more:
Looks good as always. Why the switch back to 480? Nothing wrong with it, because it looks boss with that backplate. Just curious.AlDyer (Click to show)
Originally Posted by AlDyer
The H100 was broken so I ordered a H220 instead, which I had to RMA, because it was broken out of box -.-
I will post pics with H220 later. Need some sleeved extensions too
But yeah, go ahead and give it a rating..
Not having any luck with AIO cooler's. Hope things work out if they haven't already. Try to hide the fan cables on the bottom, really noticeable. Tighten up the GPU cables. The front panel cables could be tightened up as well. Clean looking rig though. 9/10famous1994 (Click to show)
Originally Posted by famous1994
8/10 You need a sleeved PSU and re-route your SATA cables. They easily could be hidden, other than that great job
PS:Wow your cooler is huge! It's literally half the size of your board!
Re-did mine after swapping boards and adding a HD7970.
Really clean work you did there bud. Everything looks really good in there from the bottom of the case to the top. 9/10Skiivari (Click to show)
Originally Posted by Skiivari
Having had my case finished for a few months, here's a quick pic with some small wires dangling around, fixed now but I don't want to dive under my desk again
And yes, I only have one hdd on the floor, it's a minimalistic approach (Also, I removed "unnecessary" wires from the PSU while sleeving, and I sort of need them for another HDD
Man, those cables match the Noctua fans really well. I'd like to see what you did to clean up the look of the cables. it's a 8.5 for now. Theelichtje (Click to show)
Originally Posted by Theelichtje
Well, i did my best. Thinking of cutting the hard drive bays and turning them around so that the cables from the drives go out the side of the case.
The Hades case, did a build in one of those for a buddy. Very little to no room in the back for cable management. The bottom looks pretty clean. The clutter seems to be coming from the HDD's. Try to have the bend going in-between the HDD's, it looks like it'll fit. Would def. clean up that area. Route the 8 pin behind the mobo and through the CPU cut out, it'll should work. Get rid of the 24pin cable slack and tighen up the front panel cables on the top right. Not bad though, just do a little more work and it'll look awesome. 7.8/10.magreddog (Click to show)
Originally Posted by magreddog
How about this haf x setup (new on the forums)
The pics a little dark, so it's hard to rate. I can see the front panel cables and 24pin cable....from the looks of it, looks pretty clean. I would try to hide the Pump cable. Minus the dark pic, it looks alright. 8.5/10Fishinfan (Click to show)
Originally Posted by Fishinfan
Here's my first attempt at cable management.
I kind of regret buying blue sata cables.It will be changed with my new mobo soon.
The blue sata cables do stick out a lot in there. Nothing I would change in there. Everything looks clean tight. Nice job. 9/10.VindalooJim (Click to show)
Originally Posted by VindalooJim
Sorry for the poor picture quality.
The blue cables really complement those color of the noctua fans. Clean build bud. I would clean up the top GPU cable, maybe make it uniform with the bottom on. Also, try to hid the cable behind the HDD cage. Other than that, it's a really clean build. 9.5/10.Edited by mironccr345 - 4/5/13 at 11:26am
