PCI or AGP slot? Need help identifying... - Page 4

post #31 of 32
agp version 2 or 3 but no one
OoGhiJ MIQtxxXA
(13 items)


CPUMotherboardGraphicsRAM
q9550 E0 @3.825ghz Abit IX48-GT3 Tigerforce SPARKLE GTX470 850c/1800m 220 650c sli later 4GB DDR3 Mushkin blackline 7-8-7-24-1T 1200mhz
Hard DriveOptical DriveOSMonitor
WD1tb +WD500gb +WD200gb not like I need one edge linux LG 22" w2240 +optiquest q71
KeyboardPowerCaseMouse
Adesso MKB-135B Mechanical DELTA GPS-750B A 750w sleeved moded Kandalf LCS Razer Mamba
Mouse Pad
don't got one or need one
  hide details
Reply
OoGhiJ MIQtxxXA
(13 items)


CPUMotherboardGraphicsRAM
q9550 E0 @3.825ghz Abit IX48-GT3 Tigerforce SPARKLE GTX470 850c/1800m 220 650c sli later 4GB DDR3 Mushkin blackline 7-8-7-24-1T 1200mhz
Hard DriveOptical DriveOSMonitor
WD1tb +WD500gb +WD200gb not like I need one edge linux LG 22" w2240 +optiquest q71
KeyboardPowerCaseMouse
Adesso MKB-135B Mechanical DELTA GPS-750B A 750w sleeved moded Kandalf LCS Razer Mamba
Mouse Pad
don't got one or need one
  hide details
Reply
post #32 of 32
Quote:
Originally Posted by jethro_static View Post
This is your board
That is not the board in the first post. It doesn't have the PSU connector in that location, for one, but it may be a similar board from the same brand (appears to be MSI).

A rules of thumb is, if an AGP video card fits into an AGP slot, it will work.

http://www.playtool.com/pages/agpcompat/agp.html
Quote:
Practical AGP Compatibility

The previous table shows that there are combinations of motherboards and video cards which can be plugged together but do not work. According to the AGP specifications there should be no damage, but the combination would not be compatible. You see people posting in forums worrying about this possibility all the time. There are also stories that you can get some 0.8 volt only cards which are willing to tolerate 1.5 volts but that you really shouldn't plug them into an AGP 4X motherboard even if they work. Given the previous table, the confusion is understandable. But there are two pieces of information which they're missing: nobody makes AGP 3.0 cards, and nobody makes AGP 3.0 motherboards. At least not any manufacturers I can find. Every single video card I could find which claimed to be an AGP 3.0 card was actually a universal 1.5V AGP 3.0 card. And every motherboard which claimed to be an AGP 3.0 motherboard turned out to be a universal 1.5V AGP 3.0 motherboard. It makes sense, if you think about it, because if anyone actually shipped a consumer-oriented product which supported only 0.8 volts, they would end up with lots of confused customers and a support nightmare. In the consumer market, you'd have to be crazy to ship a 0.8 volt only product. And as far as I can tell, there aren't any in the workstation market either. There may be some obscure product somewhere, but I sure can't find any. It's easy to find ones which are mislabeled as AGP 3.0 cards or motherboards but I haven't been able to find the actual item.

That's why "If an AGP card fits in an AGP slot then they are compatible" is actually correct if you only consider stuff you can really buy.

Edited by Princess Garnet - 4/8/11 at 5:40am
