Greetings Everyone

Yes I know my other build ANT hasnt been updated in a while, that is because I've been busy with this build.


What is this build all about ?


I am doing a build for my little brother. He needs a simple machine, just powerful enough for the regular day to day stuff. Browsing/Music etc.
His birthday is on the 13th of June and I plan to gift this to him.




Why call it Gemini ?

My brother is a Gemini. So decided to call it that.


Alright enough.. Can we get to the details now ?


This build is going to be centered around modding a Lian Li PC-Q7.It is an extremely small case as you will see. I wanted to fit a decently sized CPU cooler in the case. Yes this is an air cooled log.. No watercooling... sorry



What to expect during the course of this mod.?


1. A fully painted chassis (Duplicolor Mirage)
2. Laser Cut custom acrylic side panels.
3. Laser Cut Custom acrylic Back Panel
4. Cable Sleeving
5. A little bondo work


The Components

1. ZOTAC NF610I-D-E LGA 775 NVIDIA GeForce 7050 Mini ITX Intel Motherboard - Retail
2. Intel Pentium E5200 Wolfdale 2.5GHz
3. Noctua NH-C12P 120mm SSO CPU Cooler - Retail
4. GeIL Black Dragon 4GB (2 x 2GB) 240-Pin DDR2 SDRAM DDR2 800
5. LG 22X DVD±R DVD Burner with LightScribe
6. SAMSUNG Spinpoint F1 HD102UJ 1TB
7. Micro-ATX PSU. (Some OEM)

Thanks for Looking,
-wasted

Never agrue with an idiot. They drag you down to their level and then beat you with their experience.

Complete - Gemini -Lian-Li PC-Q7 Mini-ITX

In Progress: ANT - NZXT Rogue SFF

Completed: Storm

Completed : Azure - A Rack Server Mod



wastedtime is offline
Sponsored Links
Advertisement

post #2 of 85 (permalink) Old 05-21-2009, 12:08 PM - Thread Starter
New to Overclock.net

wastedtime's Avatar

Join Date: Nov 2007
Location: Massachusetts
Posts: 1,025
Rep: 84 (Unique: 57)
wastedtime is offline
post #3 of 85 (permalink) Old 05-21-2009, 12:10 PM

Join Date: Mar 2008
Posts: 11,408
Not to be consufed with Syrillian's Gemini I presume?
SmasherBasher is offline
Sponsored Links
Advertisement

post #4 of 85 (permalink) Old 05-21-2009, 12:11 PM - Thread Starter
New to Overclock.net

wastedtime's Avatar

Join Date: Nov 2007
Location: Massachusetts
Posts: 1,025
Rep: 84 (Unique: 57)
Quote:
Originally Posted by SmasherBasher View Post
Not to be consufed with Syrillian's Gemini I presume?
no. That one was a monster. This one is the exact opposite

Never agrue with an idiot. They drag you down to their level and then beat you with their experience.

Complete - Gemini -Lian-Li PC-Q7 Mini-ITX

In Progress: ANT - NZXT Rogue SFF

Completed: Storm

Completed : Azure - A Rack Server Mod



wastedtime is offline
post #5 of 85 (permalink) Old 05-21-2009, 12:56 PM - Thread Starter
New to Overclock.net

wastedtime's Avatar

Join Date: Nov 2007
Location: Massachusetts
Posts: 1,025
Rep: 84 (Unique: 57)
This case is an extremely small one. Measures just 7.6" x 8.3" x 11.4". Lian-Li designed this case to accommodate a full size PSU. But why would anyone want to put a full size PSU into a Mini-ITX case ? :swearing:
In the stock placement of things the motherboard and the PSU sit parallel to each other.. and the PSU will sit extremely close to the CPU cooler . This arrangement seems like a pretty bad idea to me.. how does the CPU cooler draw in air ??

Enough of ranting.. Time for some pictures...

The stock case






Its tiny ...





Here's the case with the Motherboard and CPU cooler mounted. The problem is pretty obvious here there is no space to mount the PSU.




So here's my solution. Use a micro ATX PSU and mount it at the bottom of the case. In such a situation there is minimal impact on the structure of the case itself or component placement.
