I thought I would post a build log for my new case I just bought. I bought a old server case to replace my modded CM Stacker 810 because, the stacker was just too heavy and big. I plan to mod the heck out of this case, so I hope you guys like it =P

The Hardware

* XFX 780i
* Q6600
* 2x 8800GT
* 2x 2gb OCZ Platinum Reversion 2
* Corsair 750w psu
* 500gb Seagate, 320gb WD, 160 seagate

Watercooling

* D-tek v1 waterblock
* 2x D5 pumps with nozzle mod
* 360 GTX radiator
* 240 GTS radiator
* 2x Swiftech MCW60

Plans

*Fit a 360GTX radiator diagonally at the top
*Mount a 240GTS radiator vertically on the right side above the mobo tray
*Paint the case flat black
*door window mod and ventilation
*Fit a fan controller between top rad and psu
*add 80mm fan on back wall
*add 120mm fan on the floor
*New power button
Updates
Update 2 http://www.overclock.net/case-mod-wo...ml#post6706016
Update 3 8/2/09 http://www.overclock.net/case-mod-wo...ml#post6841552
Update 4 8/8/09 http://www.overclock.net/case-mod-wo...ml#post6893414
Update 5 8/13/09 http://www.overclock.net/case-mod-wo...ml#post6934992
Update 6 8/16/09 http://www.overclock.net/case-mod-wo...ml#post6961346


Completed Shots
















Case Arrival

This is were im going to do my modding for the next few days








Day 1






Day 2


This is my mounting for my 240 GTS radiator


These are some tabs i cut out to rivet the sheets of metal to my case




Working on the 360GTX mounting


·
Registered
Joined
·
798 Posts
Discussion Starter #3
Quote:

Originally Posted by soulsonicforce View Post
This kind of UV case stuff is just stunning:

http://www.overclock.net/album.php?albumid=618
I love uv stuff, but for this I was thinking more sleek and simple maybe a flat black with white and red lights or something like that, but thanks for the advice


btw update


·
Registered
Joined
·
798 Posts
Discussion Starter #7
I got a lot done today
I pretty much finished all the case work that needed to be done. The only things that I have left to do is paint, lazer cut the window, and drill holes for handles when they arrive.

Now for pics

Day 3




These are custom mounts for my zalman fan controller.

[URL=http://i457.photobucket.com/albums/qq291/Karyuko]http://i457.photobucket.com/albums/qq291/Karyuko[/URL]
/0716091231.jpg
I ran out of drive bays XD but I think it looks awesome with a psu and everything in











The fan on the left still needs some work done to it.

And thats all for today folks


·
Registered
Joined
·
798 Posts
Discussion Starter #9
Sorry for the long wait.

I decided what color scheme I wanted to go with, I decided to go with a white, orange and black
Anyways heres some pics





Putting on the primer.


I went with a flat black and it looks amazing. The last time I did a gloss and dust and fingerprints were everywhere.








More packages should be coming later this week =)


·
d[ o_0 ]b
Joined
·
7,316 Posts
wow that case is ridiculous


·
Registered
Joined
·
828 Posts
Epic. I love it. Good luck on the mod mate +1


·
Registered
Joined
·
1,434 Posts
Very nice mod! I'm surprised that you were about to put all of that stuff into that case! REP+


·
Registered
Joined
·
798 Posts
Discussion Starter #20
Quote:


Originally Posted by neDav
View Post

Nice work, can't wait to see the end results.... Btw, how many coats of primer/paint do you use? No matter what I do, mine would often flake off.

I used 1 very thick coat of primer and one thin coat of primer and 2 coats of flat black. Thats strange that it would flake off? Maybe the paints bad or something?

Quote:


Originally Posted by Chaos Assasson
View Post

you should put a mini-itx mobo above your psu and use it for folding

Thats not a bad idea, I might when I have more money to spend lol

Quote:


Originally Posted by kidshenlong
View Post

Epic. I love it. Good luck on the mod mate +1


Thank you


Heres a little peek at my next project
Attachment 119123
