Discussion Starter #1


Welcome All

Thanks for looking at my build, comments are welcome, lets just keep them constructive rather than opinionated. I've done my research on PC parts and software, and feel that this suits my needs. Plus I finally have the ability to begin such a project. I'm no expert so its not going to look perfect, but as much OCD as I have it will be pretty darn close




************************************************** ************************

Case:
NZXT | TEMPEST [EVO]
$109.99



CPU:
AMD | PHENOM II | X4 | 955BE | 3.2GHz
$159.99



MB:
MSI | 790FX-GD70
$135.99



GPU:
XFX | Radeon | HD5770 XXX
HD-577A-ZNDC
$174.99



RAM:
Corsair Vengeance | DDR3 1600 | 2x4Gb | 8-9-8-20-1T | 1.5V
CMZ8GX3M2A1600C9
$134.99



HDD:
WD | VelociRaptor | 300GB
Western Digital WD3000HLFS
Samsung | Spinpoint | 2TB(x2)
F3 HD203WI
$199.99
$279.98





Opticals:
LITE-ON | DVD
iHAS424-98FS
$31.99
LG | Blu-Ray
UH10LS20
$104.99



PSU:
CORSAIR | 750TX
$109.99



Monitor:
Samsung | BX2431 | LED
Samsung | PN58B860 | 58" Plasma
(Way to much, but it was worth it)



OS:
Windows 7 Pro
$135.99

Cost thus far
1,676.20
(including S/H)

Pictures:

Album Overclock.net

Full gallery on Photobucket

Again, Thanks for the views and hope y'all enjoy







·
Registered
Joined
·
85 Posts
Discussion Starter #3
8 March 2010

And so it begins:

Todays Arrival



Plain Jane Boxing



Standard stuff



And it sees Daylight (well luminescent bulbs anyway)



MMmmmm.... Even has the new plastic smell



Now onto the new home



First gotta get it out of its prison



Ah fresh Meat



And from the rear



Now time to start Breakdown



·
Registered
Joined
·
85 Posts
Discussion Starter #4
(continued)

Look at all that space



Facepiece removed to show front mounted fans



Removable HDD cages so can customize where I want to put them



Now got it laid over and just begging to be stuffed



Ahh, much better



Time for a Close up (quality kinda sucks but its an iPhone, gotta use what ya got)



Now to mock up standard top piece connections.....Yea it will look better later



·
Registered
Joined
·
85 Posts
Discussion Starter #5
10 March 2010

New day and some more stuff has Arrived




Now getting to the good stuff





Corsair TX750W Power Supply (Just if you couldn't read it in the Picture)





So thats what the extra $$$ is for, a fancy Velvet case (if it were purple and had a Crown on it then it would be better than perfect)



Yep now its time to get to work



Just nagging me to get it out and running





Yall are about to be come very close friends



·
Registered
Joined
·
85 Posts
Discussion Starter #6
(continued)

All snug in its new home



Starting the cable management





So now with power hooked up time to set you in place







Now a lil bit of thermal paste (Arctic Silver 5)





Now to attach the heatsink (PITA, prolly cause never installed one before)





Step back and take a look...... So far so good




Time for the first power test..........



SUCCESS!!!!! Now to get those fan wires outta the way



OoOoOoOooo.....Shiny



My OCD and this work area are not getting along, but a necessary evil for the time being



Waiting to arrive: should be tomorrow....(come on newegg dont let me down)

XFX ATi Radeon HD 5770xxx
G.Skill ripjaws 2x2Gb DDR3 1600 DC
WD Velociraptor 300Gb 10,000rpm HDD
Lite-on iHAS424-98 optical drive

Until next time...........


·
Registered
Joined
·
1,781 Posts
Great work man! I love that mother board, I did used one in my "Draco" build and it is so cool. Quadfire anyone? So cool!

I like your OP I need to take some pointers from you for organzing your build post. The banner looks cool and the album on Flickr seem like a good idea.

BTW the black PCB board on the mobo and your black case look posh man, good idea on the color scheme.

Quote:
Until next time...........
Wait your aren't Rodney Reynolds are you?????


·
Registered
Joined
·
1,241 Posts
Love the case looks nice and how the cable management is progressing looks nice!


·
Registered
Joined
·
85 Posts
Discussion Starter #11
So finally back at home (for a couple days anyway) and what better way to enjoy it by getting putting this thing together


Now to the newest -- (sorry had to switch host sites due to too many uploads
)

Lite-On Dvd drive and a White Box......



Since I like shiney, vibrant packaging, the Optical drive makes the first appearence





So, what was hidden in the lil white box.....



BUBBLEWRAP!!!! Sweet!

(after 2 minutes of popping bubbles here is what it had been charged to protect)







So now all is out and about, its time to get comfortable in the new home

Lite-On drive first







And now the workhorse





All wired up and ready to get under way



Yes its messy, but cant see it anyway



Power ON!!





All looking good so far, now just had to wait a week for the Graphics card and memory <_< (so much for overnight shipping)


.


·
Registered
Joined
·
85 Posts
Discussion Starter #12
After a week of travels, and other business dealings, I arrive home to yet another newegg.com cardboard box

(which as you can tell is just a normal box so figured jump right into its contents)



Another White Box!! Well lets look in it this time to behold the newest surprise



MORE BUBBLEWRAP!!!

........
....
.......
...
....

erm...Back on subject -- New DDR3 G.Skill Ripjaw Memory





And I have seen many debates on Xfire and what could be better and blah...blah...blah... But after many reviews from many different sites I felt that this would suit my needs more so than anything else (I'm not a huge gamer, but like to do so when I have a chance) So on to my finally goodie to get this thing up and running...







No Bubblewrap








So more installs (plugins nice and easy)











Install Complete (90%)......Moment of Truth.......




Awesome

.


·
Registered
Joined
·
85 Posts
Discussion Starter #13
So instead of waiting for the new OS to come in the mail (patience?? whats that?) Found a copy of XP pro laying around and figured why not give it a test to make sure all is well. Heck may even keep it if I like it (but 7pro will be on the door tomorow so we shall see)

And a quick run through the Bios to figure this thing out....









All is set and square, keeping everything stock for now. Maybe will O'c later once actually figure that part out.

Insert boot disk and "Jeopardy Music"...................
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
..

And Another Success




Well now just waiting on the new OS, Blu-Ray drive & additional Storage Drives (still debating on model/sizes) so after running through all the reboots and driver installs lets see how it gonna look on its final home



Cant wait!!

Until next time......

.


·
Registered
Joined
·
85 Posts
Discussion Starter #14
30 April 2010

So finally got back home to work on this thing some more after being on the road for a month. Heres a few shots before adding the new pieces










Now onto the newest arrivals


Standard newegg.com packing, nice and protected (for now)





Think these will be very handy just about anything I can find to put on them





Now to give them some life and least keep them from looking all shabby





Attempts to route cables out of the way..... it works for now. Just learned about extender cables so those are the next project



All plugged in and ready to rock






Now back to travels for another month and hopefully next update has some better upgrades


untill next time.................................


·
Registered
Joined
·
11 Posts
Nicely composed log! I'm really enjoying reading.. looking forward to your next upgrades.

I'm guessing cpu cooling :>


·
Registered
Joined
·
85 Posts
Discussion Starter #18
Thanks, but of course there is never an end result. Modders cant be happy
Its actually about to swap out to a different case (smaller desktop) and using the case its in now to house a seperate home NAS server. Doing the research on it now to figure out what needs to be done. Ill hopefully be adding some more info here soon.


·
Registered
Joined
·
85 Posts
Discussion Starter #19
Finally gonna add a new pic up of all my new stuff


Samsung BX2431 Monitor
Logitech K350 Wireless Keyboard
Pair of cheap wall-e-world logitech speakers to travel with

and the sneak peak of the new cooler (go for GLOW!!)


Enjoy!



BTW I am hoping to get some time off that (or at home at least) to where I can take the entire thing apart and put back together in a new case and do another log with better pictures than what this iphone allows


·
Registered
Joined
·
409 Posts
Very nice build so far... seems like you always get a nice 'welcome home' gift. Beats what I get... Hi Honey I'm home..... will you please change both poo diapers and feed the kids! at least she says please
